91 TRG LOW O Trigger motor HIGH/LOW control output. Not used (Open).
––––––––––––––––––––––––
92 CAP • M ON O Capstan motor ON/OFF control output. Not used (Ground).
–––––––––––––––––
93 STEREO I FM/AM Stereo identification. L : Stereo
–––––––––––––––
94 TUNED I FM/AM Tuning identification. L : Tuning
95 ST-CE O Chip enable output to Tuner.
––––––––––––––––––––––––––––––––––––
96 DELAY SEL • MIC O Not used (Ground).
–––––––––––––––––––––––
97 DELAY ON O Delay ON/OFF control output. Not used (Ground).
98 DELAY LEVEL-A O Delay level control output. Not used (Ground).
99 DELAY LEVEL-B O Delay level control output. Not used (Ground).
100 VDD – Power supply. (+5V)
Pin No. Pin name I/O Description
