IC1202 8-759-111-68 IC UPC1237HA
< JACK >
J801 1-774-725-11 JACK, PIN 2P (VIDEO)
J802 1-774-785-11 JACK, PIN 1P (SUPER WOOFER) (H331)
< COIL >
L301 1-410-780-11 INDUCTOR 27mH
L351 1-414-223-11 INDUCTOR 470uH
L401 1-410-780-11 INDUCTOR 27mH
< TRANSISTOR >
Q301 8-729-119-79 TRANSISTOR 2SC2785-HFE
Q351 8-729-194-57 TRANSISTOR 2SC945-P
Q352 8-729-194-57 TRANSISTOR 2SC945-P
Q353 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q354 8-729-119-79 TRANSISTOR 2SC2785-HFE
Q380 8-729-900-89 TRANSISTOR DTC144ES
Q381 8-729-900-65 TRANSISTOR DTA144ES
Q382 8-729-900-89 TRANSISTOR DTC144ES
Q401 8-729-119-79 TRANSISTOR 2SC2785-HFE
Q450 8-729-900-65 TRANSISTOR DTA144ES
Q451 8-729-900-89 TRANSISTOR DTC144ES
Q701 8-729-620-05 TRANSISTOR 2SC2603-EF1
Q820 8-729-422-57 TRANSISTOR UN4111
Q901 8-729-620-05 TRANSISTOR 2SC2603-EF1
Q902 8-729-620-05 TRANSISTOR 2SC2603-EF1
Q951 8-729-620-05 TRANSISTOR 2SC2603-EF1
Q952 8-729-620-05 TRANSISTOR 2SC2603-EF1
Q953 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q954 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q1001 8-729-118-01 TRANSISTOR 2SB1116-K
Q1002 8-729-900-36 TRANSISTOR DTC124ES
Q1006 8-729-141-83 TRANSISTOR 2SB1094-LK
Q1011 8-729-209-15 TRANSISTOR 2SD2012
Q1201 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q1202 8-729-620-05 TRANSISTOR 2SC2603-EF1
Q1203 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q1204 8-729-900-63 TRANSISTOR DTA124ES
Q1205 8-729-900-36 TRANSISTOR DTC124ES
Q1206 8-729-900-80 TRANSISTOR DTC114ES
Q1207 8-729-422-57 TRANSISTOR UN4111
Q1251 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R201 1-249-415-11 CARBON 680 5% 1/4W
R202 1-249-435-11 CARBON 33K 5% 1/4W
R203 1-249-425-11 CARBON 4.7K 5% 1/4W
R208 1-249-425-11 CARBON 4.7K 5% 1/4W
R251 1-249-415-11 CARBON 680 5% 1/4W
R252 1-249-435-11 CARBON 33K 5% 1/4W
R301 1-247-889-00 CARBON 270K 5% 1/4W
R302 1-249-404-00 CARBON 82 5% 1/4W
R303 1-247-882-11 CARBON 130K 5% 1/4W
R304 1-247-850-11 CARBON 6.2K 5% 1/4W
R311 1-247-889-00 CARBON 270K 5% 1/4W
R312 1-249-404-00 CARBON 82 5% 1/4W
R313 1-247-882-11 CARBON 130K 5% 1/4W
R314 1-247-850-11 CARBON 6.2K 5% 1/4W
R315 1-247-863-91 CARBON 22K 5% 1/4W
R320 1-249-432-11 CARBON 18K 5% 1/4W
R321 1-249-429-11 CARBON 10K 5% 1/4W
R322 1-249-431-11 CARBON 15K 5% 1/4W
R323 1-249-429-11 CARBON 10K 5% 1/4W
R324 1-249-425-11 CARBON 4.7K 5% 1/4W
R325 1-249-421-11 CARBON 2.2K 5% 1/4W
R326 1-249-428-11 CARBON 8.2K 5% 1/4W
R327 1-247-840-00 CARBON 2.4K 5% 1/4W
R328 1-247-863-91 CARBON 22K 5% 1/4W
R329 1-249-417-11 CARBON 1K 5% 1/4W
R331 1-249-430-11 CARBON 12K 5% 1/4W
R351 1-249-434-11 CARBON 27K 5% 1/4W
R352 1-249-434-11 CARBON 27K 5% 1/4W
R353 1-249-389-11 CARBON 4.7 5% 1/4W
R354 1-249-389-11 CARBON 4.7 5% 1/4W
R355 1-249-429-11 CARBON 10K 5% 1/4W
R381 1-249-413-11 CARBON 470 5% 1/4W
R382 1-249-413-11 CARBON 470 5% 1/4W
R383 1-249-413-11 CARBON 470 5% 1/4W
R384 1-249-413-11 CARBON 470 5% 1/4W
R387 1-249-417-11 CARBON 1K 5% 1/4W
R388 1-249-429-11 CARBON 10K 5% 1/4W
R390 1-249-417-11 CARBON 1K 5% 1/4W
! R391 1-215-905-11 METAL OXIDE 10 5% 3W F
R401 1-247-889-00 CARBON 270K 5% 1/4W
R402 1-249-404-00 CARBON 82 5% 1/4W
R403 1-247-882-11 CARBON 130K 5% 1/4W
R404 1-247-850-11 CARBON 6.2K 5% 1/4W
R411 1-247-889-00 CARBON 270K 5% 1/4W
R412 1-249-404-00 CARBON 82 5% 1/4W
R413 1-247-882-11 CARBON 130K 5% 1/4W
R414 1-247-850-11 CARBON 6.2K 5% 1/4W
R415 1-247-863-91 CARBON 22K 5% 1/4W
R421 1-249-429-11 CARBON 10K 5% 1/4W
R422 1-249-431-11 CARBON 15K 5% 1/4W
R423 1-249-429-11 CARBON 10K 5% 1/4W
R424 1-249-425-11 CARBON 4.7K 5% 1/4W
R425 1-249-421-11 CARBON 2.2K 5% 1/4W
R426 1-249-428-11 CARBON 8.2K 5% 1/4W
R427 1-247-840-00 CARBON 2.4K 5% 1/4W
R428 1-247-863-91 CARBON 22K 5% 1/4W
R429 1-249-417-11 CARBON 1K 5% 1/4W
R431 1-249-430-11 CARBON 12K 5% 1/4W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
MAIN
