– 66 –
S522 1-762-196-21 SWITCH, TACT (DOLBY NR)
S524 1-762-196-21 SWITCH, TACT (MENU 1)
S525 1-762-196-21 SWITCH, TACT (MENU 2)
S526 1-762-196-21 SWITCH, TACT (MENU 3)
S528 1-762-196-21 SWITCH, TACT (P FILE)
S529 1-762-196-21 SWITCH, TACT (EFFECT ON/OFF)
S530 1-762-196-21 SWITCH, TACT (SURROUND)
S531 1-762-196-21 SWITCH, TACT (EQ EDIT)
S532 1-762-196-21 SWITCH, TACT (ª)
S533 1-762-196-21 SWITCH, TACT (¢)
S534 1-762-196-21 SWITCH, TACT (·)
S535 1-762-196-21 SWITCH, TACT (›)
S536 1-762-196-21 SWITCH, TACT (TUNER/BAND)
S537 1-762-196-21 SWITCH, TACT (FUNCTION)
S538 1-762-196-21 SWITCH, TACT (GROOVE)
S550 1-467-869-11 ENCODER, ROTARY (VOLUME)
< VIBRATOR >
X501 1-579-233-11 VIBRATOR, CERAMIC (5MHz)
************************************************************
* 1-658-576-11 SENSOR BOARD
*************
< IC >
IC702 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
IC703 8-749-924-30 IC PHOTO REFLECTOR GP2S28
< RESISTOR >
R701 1-249-416-11 CARBON 820 5% 1/4W
R702 1-249-407-11 CARBON 150 5% 1/4W
************************************************************
* 1-659-148-11 TRANSFORMER BOARD
*******************
1-533-217-31 HOLDER, FUSE
< CONNECTOR >
CN1601 1-564-321-00 PIN, CONNECTOR 2P
CN1602 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
< FUSE >
! F1601 1-532-350-00 FUSE, TIME LAG (T4.0A/250V) (E,AUS,MX,AR)
! F1601 1-533-419-11 FUSE, GLASS CYLINDRICAL(DIA.5)(4.0A/125V)
(US,Canadian)
! F1602 1-532-350-00 FUSE, TIME LAG (T4.0A/250V) (E,AUS,MX,AR)
! F1602 1-533-419-11 FUSE, GLASS CYLINDRICAL(DIA.5)(4.0A/125V)
(US,Canadian)
< RESISTOR >
! R1600 1-202-725-00 SOLID 3.3M 10% 1/2W
(US,Canadian)
! R1601 1-217-637-00 FUSIBLE 1 5% 1/4W F
< SWITCH >
! S1601 1-572-675-11 SWITCH, POWER VOLTAGE CHANGE (E,AR)
************************************************************
MISCELLANEOUS
**************
7 1-233-544-11 ENCAPSULATED COMPONENT
(US, Canadian,MX)
7 1-233-545-11 ENCAPSULATED COMPONENT (E,AUS,AR)
9 1-769-977-11 WIRE (FLAT TYPE) (13 CORE)
11 1-776-240-11 WIRE (FLAT TYPE) (19 CORE)
! 13 1-575-651-11 CORD, POWER (AR)
! 13 1-575-653-11 CORD, POWER (E,MX)
! 13 1-690-608-11 CORD, POWER (AUS)
! 13 1-690-609-21 CORD, POWER (US,Canadian)
65 1-773-020-11 WIRE (FLAT TYPE) (15 CORE)
121 1-698-705-11 MOTOR, WIRE
151 1-500-322-11 HEAD, WIRE (E) (DECK B)
153 1-500-319-11 HEAD, HOLDER (DECK B)
155 1-500-320-11 HEAD, WIRE R/P (DECK B)
156 1-500-321-11 HEAD, WIRE P.B (DECK A)
214 1-762-610-11 SWITCH, PLATE
215 1-762-613-11 SWITCH, WIRE LEAF (DECK A)
216 1-762-612-11 SWITCH, WIRE LEAF (DECK B)
307 1-452-538-11 MAGNET
308 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
316 1-776-442-11 WIRE (FLAT TYPE) (19 CORRE)
! 351 8-848-367-11 OPTICAL PICK-UP KSS-213BA/F-NP
352 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
! F1601 1-532-350-00 FUSE, TIME LAG (T4.0A/250V) (E,AUS,MX,AR)
! F1601 1-533-419-11 FUSE, GLASS CYLINDRICAL(DIA.5)(4.0A/125V)
(US,Canadian)
! F1602 1-532-350-00 FUSE, TIME LAG (T4.0A/250V) (E,AUS,MX,AR)
! F1602 1-533-419-11 FUSE, GLASS CYLINDRICAL(DIA.5)(4.0A/125V)
(US,Canadian)
FL501 1-517-489-11 INDICATOR TUBE, FLUORESCENT
HE1 1-500-318-11 HEAD, E (ERASE)(DECK B)
HP1 1-543-424-21 HEAD (PLAYBACK) (DECK A)
HRPE1 1-543-424-21 HEAD (RECORD/PLAYBACK) (DECK B)
M1 X-3372-231-1 MOTOR ASSY (CAPSTAN/REEL)
M101 X-4917-523-4 BASE OUTSERT ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M701 A-4660-586-A MOTOR ASSY (TURN)
M801 A-4660-586-A MOTOR ASSY (SLIDE)
S1 1-571-556-11 SWITCH, LEAF (MOTOR) (DECK A)
S2 1-571-745-11 SWITCH, LEAF (PLAY) (DECK A)
S3 1-762-611-11 SWITCH, LEAF (TYPE 2) (DECK A)
S4 1-571-556-11 SWITCH, LEAF (MOTOR) (DECK B)
S5 1-571-745-11 SWITCH, LEAF (PLAY) (DECK B)
S6 1-762-611-11 SWITCH, LEAF (TYPE 2) (DECK B)
S7 1-571-556-11 SWITCH, LEAF (REC) (DECK B)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
TRANSFORMER
SENSOR
PANEL
To Next Page
