CD MECHANISM DECK (CDM37L-5BD34L)
3 three screws
(BVTP3 × 8)
3 three screws
(BVTP3 × 8)
2 connector
(CN412)
1 wire (flat type) (13 core)
(CN411)
5 Open the cable clamp.
4
4
6
3 two screws
(BVTP3 × 8)
2 connector
(CN701)
7 five screws
(BVTP3 × 8)
q; CD mechanism deck
(CDM37L-5BD34L)
9 wire (flat type) (23 core
)
(CN101)
8
