HCD-LX10000
SECTION 3
DISASSEMBLY
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
3-2.SIDE PANEL, TOP CASE
(Page 8)
3-3.LOADING PANEL ASSY
(Page 8)
3-4.FRONT PANEL ASSY
(Page 9)
3-5.TUNER PACK
(Page 9)
3-13.POWER TRANSFORMER
(T1200)
(Page 13)
3-11.POWER AMP PC BOARD ASSY,
MAIN BOARD
(Page 12)
3-8.CD MECHANISM DECK
(Page 11)
3-7.PANEL BOARD,
CD-SW BOARD
(Page 10)
3-6.TAPE MECHANISM DECK,
MIC BOARD
(Page 10)
3-14.DRIVER BOARD,
SW BOARD
(Page 14)
3-10.PRIMARY BOARD,
LIGHTING BOARD
(Page 12)
3-17.MOTOR (TB) BOARD
(Page 15)
3-18.MOTOR (LD) BOARD
(Page 16)
3-16.SENSOR BOARD
(Page 15)
3-12.SURROUND BOARD,
PA BOARD
(Page 13)
3-9.BACK PANEL
(Page 11)
3-15.CD BOARD,
OPTICAL PICK-UP
(KSM-215DCP/C2NP)
(Page 14)
SET
