Sony HCD-MD313 - Adjustment and Connection Point Locations; BD (MD) Board (Side A) Connection Points; BD (MD) Board (Side B) Connection Points

– 23 –
5-11. ADJUSTING POINTS AND CONNECTING POINTS
[BD (MD) BOARD] (SIDE A)
[BD (MD) BOARD] (SIDE B)
IC171
IC101
Q102
IC121
IC316
Q163
TP (IOP)
TP
(VC)
TP
(TEO)
TP (I + 3V)
D101
IC192
