– 65 –
• Waveforms
– CD Section –
1 IC101 #¡ (RFO) (PLAY Mode)
500 mV/DIV, 500 ns/DIV
6 IC103 @∞ (XPCK)
5.3 Vp-p
14 ns
2 IC101 $¢ (TEI) (PLAY Mode)
50 mV/DIV, 1 µs/DIV
7 IC103 @™ (BCLK)
5 Vp-p
474 ns
3 IC101 2 (FEI) (PLAY Mode)
50 mV/DIV, 1 µs/DIV
8 IC103 @º (LRCK)
5.1 Vp-p
22.8
µ
s
4 IC103 3 (MDP) (PLAY Mode) 9 IC104 6 (XTO)
4.6 Vp-p
16.9344 MHz
5 IC103 @• (RFCK)
Approx.
150 mVp-p
2.6 Vp-p
7.6
µ
s
5.1 Vp-p
136
µ
s
1.3
±
0.3 Vp-p
– MD Section –
1 IC101 1, 2 (I, J) (PLAY Mode)
Approx.
500 mVp-p
2 IC101 4 (A) (PLAY Mode)
Approx.
200 mVp-p
1.2
±
0.2 Vp-p
4 IC101 #• (RF) (PLAY Mode)
5 IC152 #™ (CAPA–) (PLAY Mode)
4.6 Vp-p
1.5
µ
sec
3 IC101 8, 9 (E, F) (PLAY Mode)
Approx.
100 mVp-p
