– 5 –
SECTION 2
GENERAL
1 POWER button
2 MD disk slot
3 § (MD) button
4 ^ (MD) button
5 p (MD) button
6 VOLUME control knob
7 ^ (CD) button
8 p (CD) button
9 FUNCTION button
!º Fluorescent indicator tube
!¡ CD disc tray
!™ PHONES jack
!£ PLAY MODE • TUNING MODE button
!¢ REPEAT • STEREO/MONO button
!∞ § (CD) button
!§ TUNER/BAND button
!¶ CD-MD SYNC button
!• r REC button
!ª MD/CD = 0 • TUNER – button
@º MD/CD ) + • TUNER + button
1 TAPE OUTPUT pin jack
2 TAPE INPUT pin jack
3 AU BUS jack
4 SPEAKER terminal
5 VOLTAGE SELECTOR switch
(Except European models)
6 AM ANTENNA terminal
7 FM ANTENNA terminal
8 SIGNAL GND terminal
LOCATION OF CNTROLS
