– 8 –
Note: Follow the disassembly procedure in the numerical order given.
CASE
SECTION 3
DISASSEMBLY
FRONT PANEL/MD MECHANISM DECK SECTION
1
two screws
(case 3 TP2)
2
case
1
two screws
(case 3 TP2)
7
six screws (BVTT 3
×
6)
8
MD mechanism section
5
front panel section
1
two screws
(BVTP 3
×
8)
2
wire (flat type) (23 core)
(CN873)
4
claw
3
connector
(CN490)
6
wire (flat type) (25 core)
(CN820)
