– 88 –
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used on
the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark
• Abbreviation
AED : North European
CND : Canadian
G : German
HK : Hong Kong
MY : Malaysia
SP : Singapore
AUDIO
When indicating parts by reference
number, please include the board.
* A-4403-412-A AUDIO BOARD, COMPLETE (AEP, UK, G, AED)
* A-4403-419-A AUDIO BOARD, COMPLETE (MY, SP, HK)
* A-4407-387-A AUDIO BOARD, COMPLETE (CND)
**********************
< CAPACITOR >
C701 1-126-163-11 ELECT 4.7uF 20% 50V
C702 1-126-163-11 ELECT 4.7uF 20% 50V
C703 1-126-163-11 ELECT 4.7uF 20% 50V
C704 1-126-163-11 ELECT 4.7uF 20% 50V
C705 1-126-163-11 ELECT 4.7uF 20% 50V
C706 1-136-165-00 FILM 0.1uF 5% 50V
C707 1-124-464-11 ELECT 0.22uF 20% 50V
C708 1-130-473-00 MYLAR 0.0015uF 5% 50V
C709 1-126-160-11 ELECT 1uF 20% 50V
C712 1-162-294-31 CERAMIC 0.001uF 10% 50V
C713 1-124-589-11 ELECT 47uF 20% 16V
C714 1-136-165-00 FILM 0.1uF 5% 50V
C715 1-136-165-00 FILM 0.1uF 5% 50V
C716 1-124-261-00 ELECT 10uF 20% 50V
C717 1-126-163-11 ELECT 4.7uF 20% 50V
C718 1-162-290-31 CERAMIC 470PF 10% 50V
C719 1-124-589-11 ELECT 47uF 20% 16V
C720 1-124-589-11 ELECT 47uF 20% 16V
C731 1-130-475-00 MYLAR 0.0022uF 5% 50V
C743 1-124-589-11 ELECT 47uF 20% 16V
C751 1-126-163-11 ELECT 4.7uF 20% 50V
C752 1-126-163-11 ELECT 4.7uF 20% 50V
C753 1-126-163-11 ELECT 4.7uF 20% 50V
C754 1-126-163-11 ELECT 4.7uF 20% 50V
C755 1-126-163-11 ELECT 4.7uF 20% 50V
C756 1-136-165-00 FILM 0.1uF 5% 50V
C757 1-124-464-11 ELECT 0.22uF 20% 50V
C758 1-130-473-00 MYLAR 0.0015uF 5% 50V
C759 1-126-160-11 ELECT 1uF 20% 50V
C762 1-124-261-00 ELECT 10uF 20% 50V
C763 1-130-477-00 MYLAR 0.0033uF 5% 50V
C764 1-136-165-00 FILM 0.1uF 5% 50V
C765 1-136-165-00 FILM 0.1uF 5% 50V
C766 1-124-261-00 ELECT 10uF 20% 50V
C767 1-126-163-11 ELECT 4.7uF 20% 50V
C768 1-162-290-31 CERAMIC 470PF 10% 50V
C769 1-162-294-31 CERAMIC 0.001uF 10% 50V
C781 1-130-475-00 MYLAR 0.0022uF 5% 50V
C1501 1-124-589-11 ELECT 47uF 20% 16V
(AEP, UK, G, AED)
C1502 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, UK, G, AED)
C1503 1-162-157-11 ELECT 10uF 20% 16V
(AEP, UK, G, AED)
C1504 1-162-291-31 CERAMIC 560PF 10% 50V
(AEP, UK, G, AED)
C1505 1-126-157-11 ELECT 10uF 20% 16V
(AEP, UK, G, AED)
C1506 1-124-257-00 ELECT 2.2uF 20% 50V
(AEP, UK, G, AED)
C1507 1-102-518-11 CERAMIC 33PF 5% 50V
(AEP, UK, G, AED)
C1508 1-162-288-31 CERAMIC 330PF 10% 50V
(AEP, UK, G, AED)
C1509 1-102-518-11 CERAMIC 33PF 5% 50V
(AEP, UK, G, AED)
C1510 1-162-306-11 CERAMIC 0.01uF 20% 16V
(AEP, UK, G, AED)
C1511 1-162-291-31 CERAMIC 560PF 10% 50V
(AEP, UK, G, AED)
C1512 1-162-306-11 CERAMIC 0.01uF 20% 16V
(AEP, UK, G, AED)
C1513 1-162-301-11 CERAMIC 1500PF 20% 16V
(AEP, UK, G, AED)
C1515 1-162-600-11 CERAMIC 4700PF 20% 16V
(AEP, UK, G, AED)
< CONNECTOR >
CN701 1-779-819-11 CONNECTOR, BOARD TO BOARD 14P
CN702 1-779-819-11 CONNECTOR, BOARD TO BOARD 14P
< DIODE >
D701 8-719-911-19 DIODE 1SS119
D1501 8-719-911-19 DIODE 1SS119 (AEP, UK, G, AED)
< IC >
IC701 8-759-439-30 IC M62428FP
IC702 8-759-634-51 IC M5218AP
IC1500 8-759-450-87 IC BU1922F (AEP, UK, G, AED)
IC1501 8-759-636-55 IC M5218AFP (AEP, UK, G, AED)
Les composants identifiés par une
marque ! sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
The components identified by mark
! or dotted line with mark ! are
critical for safety.
Replace only with part number
specified.
