– 93 –
JACK
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R444 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R445 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R448 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R449 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R451 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R454 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R455 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R456 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R457 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R458 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R460 1-216-073-00 METAL CHIP 10K 5% 1/10W
R462 1-216-073-00 METAL CHIP 10K 5% 1/10W
R502 1-216-295-11
CONDUCTOR, CHIP
(2012)
R504 1-216-295-11
CONDUCTOR, CHIP
(2012)
R600 1-216-053-00 METAL GLAZE 1.5K 5% 1/10W
R602 1-216-025-00 METAL GLAZE 100 5% 1/10W
R603 1-216-025-00 METAL GLAZE 100 5% 1/10W
R604 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R605 1-216-025-00 METAL GLAZE 100 5% 1/10W
R606 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R607 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R608 1-216-025-00 METAL GLAZE 100 5% 1/10W
R2001 1-216-001-00 METAL CHIP 10 5% 1/10W
R2002 1-216-296-00
CONDUCTOR, CHIP
(3216)
< VIBRATOR >
X101 1-767-151-11 VIBRATOR, CRYSTAL (22MHz)
X302 1-767-670-11 VIBRATOR, CERAMIC (7MHz)
************************************************************
* A-4403-414-A JACK BOARD, COMPLETE (AEP, UK, G, AED)
* A-4403-421-A JACK BOARD, COMPLETE (MY, SP, HK)
* A-4407-389-A JACK BOARD, COMPLETE (CND)
********************
< CAPACITOR >
C401 1-162-282-31 CERAMIC 100PF 10% 50V
C411 1-162-282-31 CERAMIC 100PF 10% 50V
C412 1-162-290-31 CERAMIC 470PF 10% 50V
C413 1-126-964-11 ELECT 10uF 20% 50V
C421 1-162-282-31 CERAMIC 100PF 10% 50V
C431 1-126-923-11 ELECT 220uF 20% 10V
C432 1-126-933-11 ELECT 100uF 20% 16V
C448 1-136-165-00 FILM 0.1uF 5% 50V
(AEP, UK, G, AED)
C449 1-136-165-00 FILM 0.1uF 5% 50V
(AEP, UK, G, AED)
C451 1-162-282-31 CERAMIC 100PF 10% 50V
C461 1-162-282-31 CERAMIC 100PF 10% 50V
C462 1-162-290-31 CERAMIC 470PF 10% 50V
C463 1-126-964-11 ELECT 10uF 20% 50V
C473 1-136-173-00 FILM 0.47uF 5% 50V
C498 1-136-165-00 FILM 0.1uF 5% 50V
(AEP, UK, G, AED)
C499 1-136-165-00 FILM 0.1uF 5% 50V
(AEP, UK, G, AED)
< CONNECTOR >
* CN401 1-568-858-11 SOCKET, CONNECTOR 15P
CN402 1-564-506-11 PLUG, CONNECTOR 3P
* CN404 1-770-379-11 CONNECTOR, BOARD TO BOARD 6P
* CN420 1-565-561-11 PIN, CONNECTOR 3P (AU BUS)
* CN430 1-565-500-11 CONNECTOR, BOARD TO BOARD 9P
* CN490 1-568-943-11 PIN, CONNECTOR 5P
< DIODE >
D422 8-719-911-19 DIODE 1SS119
D430 8-719-911-19 DIODE 1SS119
D447 8-719-911-19 DIODE 1SS119
D497 8-719-911-19 DIODE 1SS119
< JACK >
J401 1-764-767-21 JACK, PIN 2P (TAPE B INPUT)
J402 1-764-767-21 JACK, PIN 2P (TAPE A OUTPUT)
< COIL >
L448 1-420-872-00 COIL, AIR-CORE
L498 1-420-872-00 COIL, AIR-CORE
< TRANSISTOR >
Q400 8-729-620-05 TRANSISTOR 2SC2603-EF
Q410 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q420 8-729-620-05 TRANSISTOR 2SC2603-EF
Q431 8-729-900-80 TRANSISTOR DTC114ES
Q432 8-729-620-05 TRANSISTOR 2SC2603-EF
Q433 8-729-620-05 TRANSISTOR 2SC2603-EF
Q434 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q435 8-729-620-05 TRANSISTOR 2SC2603-EF
Q436 8-729-620-05 TRANSISTOR 2SC2603-EF
Q450 8-729-620-05 TRANSISTOR 2SC2603-EF
Q460 8-729-141-30 TRANSISTOR 2SC3623A-LK
< RESISTOR >
R401 1-249-417-11 CARBON 1K 5% 1/4W
R402 1-249-441-11 CARBON 100K 5% 1/4W
R403 1-249-425-11 CARBON 4.7K 5% 1/4W
R404 1-249-425-11 CARBON 4.7K 5% 1/4W
R405 1-249-429-11 CARBON 10K 5% 1/4W
R411 1-249-441-11 CARBON 100K 5% 1/4W
R412 1-249-417-11 CARBON 1K 5% 1/4W
R413 1-249-429-11 CARBON 10K 5% 1/4W
R414 1-249-421-11 CARBON 2.2K 5% 1/4W
R415 1-249-441-11 CARBON 100K 5% 1/4W
R421 1-249-393-11 CARBON 10 5% 1/4W
R422 1-249-429-11 CARBON 10K 5% 1/4W
R423 1-249-425-11 CARBON 4.7K 5% 1/4W
R431 1-249-437-11 CARBON 47K 5% 1/4W
R433 1-249-433-11 CARBON 22K 5% 1/4W
R434 1-249-431-11 CARBON 15K 5% 1/4W
R435 1-249-437-11 CARBON 47K 5% 1/4W
R436 1-249-433-11 CARBON 22K 5% 1/4W
R437 1-249-417-11 CARBON 1K 5% 1/4W
! R444 1-216-478-11 METAL OXIDE 390 5% 3W F
(AEP, UK, G, AED)
BD (MD)
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
