74
HCD-RV22/RV55
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C374 1-126-947-11 ELECT 47uF 20% 35V
C375 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C376 1-126-961-11 ELECT 2.2uF 20% 50V
< CONNECTOR >
CN101 1-568-830-11 CONNECTOR, FFC 11P
* CN103 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
* CN112 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN302 1-568-844-11 CONNECTOR, FFC 29P
* CN304 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
CN307 1-778-982-21 CONNECTOR, BOARD TO BOARD 13P
CN308 1-564-506-11 PLUG, CONNECTOR 3P
CN309 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
< DIODE >
D201 8-719-988-61 DIODE 1SS355TE-17
D202 8-719-083-63 DIODE UDZSTE-1713B
D206 8-719-988-61 DIODE 1SS355TE-17
D207 8-719-988-61 DIODE 1SS355TE-17
D211 8-719-988-61 DIODE 1SS355TE-17
D212 8-719-988-61 DIODE 1SS355TE-17
D213 8-719-988-61 DIODE 1SS355TE-17
D214 8-719-988-61 DIODE 1SS355TE-17
D215 8-719-988-61 DIODE 1SS355TE-17
D301 6-500-522-31 DIODE 10EDB40-TB5
D302 6-500-522-31 DIODE 10EDB40-TB5
D303 6-500-522-31 DIODE 10EDB40-TB5
D304 6-500-522-31 DIODE 10EDB40-TB5
D305 6-500-522-31 DIODE 10EDB40-TB5
D306 6-500-522-31 DIODE 10EDB40-TB5
D307 6-500-522-31 DIODE 10EDB40-TB5
D308 6-500-522-31 DIODE 10EDB40-TB5
D309 6-500-522-31 DIODE 10EDB40-TB5
D310 6-500-522-31 DIODE 10EDB40-TB5
D311 6-500-522-31 DIODE 10EDB40-TB5
D312 6-500-522-31 DIODE 10EDB40-TB5
D313 8-719-085-36 DIODE 11EQS04-TB5
D316 8-719-988-61 DIODE 1SS355TE-17
D321 8-719-988-61 DIODE 1SS355TE-17
D322 8-719-988-61 DIODE 1SS355TE-17
D324 6-500-522-31 DIODE 10EDB40-TB5
D325 6-500-522-31 DIODE 10EDB40-TB5
< EARTH TERMINAL >
* EP101 1-537-738-21 TERMINAL, EARTH
* EP301 1-537-738-21 TERMINAL, EARTH
< FERRITE BEAD >
FB201 1-216-864-11 SHORT CHIP 0
FB202 1-543-958-22 BEAD, FERRITE (CHIP) (1608)
FB203 1-216-864-11 SHORT CHIP 0
FB204 1-216-864-11 SHORT CHIP 0
FB205 1-216-864-11 SHORT CHIP 0
< IC >
IC101 6-705-852-01 IC BD3401KS2
IC102 8-759-710-97 IC NJM4565M-D
IC201 8-759-508-69 IC BA3126N
IC301 6-702-771-01 IC TA78033LS
IC302 8-759-231-53 IC TA7805S
IC303 8-759-701-59 IC NJM78M09FA
IC304 8-759-701-59 IC NJM78M09FA
IC371 6-704-046-01 IC BU2099FV
< JACK >
JK101 1-770-613-11 JACK, PIN 4P (VIDEO/SAT IN/OUT) (RV55)
< COIL >
L101 1-424-849-11 COIL, OSCILLATION (BIAS) (RV22)
L101 1-437-220-11 TRANSFORMER, BIAS OSCILLATION (RV55)
< TRANSISTOR >
Q101 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q102 6-550-580-01 TRANSISTOR 2SA1235TP-1F
Q103 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q104 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q105 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q106 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q107 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q301 8-729-209-60 TRANSISTOR 2SB1375
Q302 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q304 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q305 6-550-580-01 TRANSISTOR 2SA1235TP-1F
Q306 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q307 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q308 6-550-580-01 TRANSISTOR 2SA1235TP-1F
Q309 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q310 8-729-142-46 TRANSISTOR 2SC2001-LK
Q311 8-729-142-46 TRANSISTOR 2SC2001-LK
Q312 6-551-128-01 TRANSISTOR 2SA953-T-LK
Q313 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q314 6-550-580-01 TRANSISTOR 2SA1235TP-1F
Q315 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q321 8-729-142-46 TRANSISTOR 2SC2001-LK
Q322 6-550-580-01 TRANSISTOR 2SA1235TP-1F
Q323 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q324 8-729-140-04 TRANSISTOR 2SB1116A-L
Q327 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q351 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q352 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q361 6-550-580-01 TRANSISTOR 2SA1235TP-1F
Q362 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q372 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R101 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R102 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R103 1-216-851-11 METAL CHIP 330K 5% 1/10W
R104 1-216-835-11 METAL CHIP 15K 5% 1/10W
R105 1-216-816-11 METAL CHIP 390 5% 1/10W
R106 1-216-851-11 METAL CHIP 330K 5% 1/10W
R107 1-216-835-11 METAL CHIP 15K 5% 1/10W
R108 1-216-816-11 METAL CHIP 390 5% 1/10W
R109 1-216-853-11 METAL CHIP 470K 5% 1/10W
R110 1-216-851-11 METAL CHIP 330K 5% 1/10W
MAIN
