75
HCD-RV22/RV55
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R111 1-216-843-11 METAL CHIP 68K 5% 1/10W
(RV55)
R111 1-216-846-11 METAL CHIP 120K 5% 1/10W
(RV22)
R112 1-216-853-11 METAL CHIP 470K 5% 1/10W
R113 1-216-851-11 METAL CHIP 330K 5% 1/10W
R114 1-216-843-11 METAL CHIP 68K 5% 1/10W
(RV55)
R114 1-216-846-11 METAL CHIP 120K 5% 1/10W
(RV22)
R115 1-216-857-11 METAL CHIP 1M 5% 1/10W
R116 1-216-809-11 METAL CHIP 100 5% 1/10W
R117 1-216-809-11 METAL CHIP 100 5% 1/10W
R119 1-216-841-11 METAL CHIP 47K 5% 1/10W
R120 1-216-857-11 METAL CHIP 1M 5% 1/10W
R121 1-216-841-11 METAL CHIP 47K 5% 1/10W
R127 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R128 1-216-835-11 METAL CHIP 15K 5% 1/10W
R129 1-216-841-11 METAL CHIP 47K 5% 1/10W
R131 1-216-835-11 METAL CHIP 15K 5% 1/10W
R132 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R133 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R134 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R135 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R136 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R137 1-216-833-11 METAL CHIP 10K 5% 1/10W
R138 1-216-821-11 METAL CHIP 1K 5% 1/10W
R140 1-216-821-11 METAL CHIP 1K 5% 1/10W
R141 1-216-821-11 METAL CHIP 1K 5% 1/10W
R142 1-216-821-11 METAL CHIP 1K 5% 1/10W
R143 1-216-821-11 METAL CHIP 1K 5% 1/10W
(RV55)
R144 1-216-821-11 METAL CHIP 1K 5% 1/10W
(RV55)
R145 1-216-845-11 METAL CHIP 100K 5% 1/10W
(RV55)
R146 1-216-845-11 METAL CHIP 100K 5% 1/10W
(RV55)
R147 1-216-821-11 METAL CHIP 1K 5% 1/10W
(RV55)
R148 1-216-821-11 METAL CHIP 1K 5% 1/10W
(RV55)
R149 1-216-845-11 METAL CHIP 100K 5% 1/10W
(RV55)
R150 1-216-845-11 METAL CHIP 100K 5% 1/10W
(RV55)
R151 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R152 1-216-833-11 METAL CHIP 10K 5% 1/10W
R153 1-216-833-11 METAL CHIP 10K 5% 1/10W
R154 1-216-833-11 METAL CHIP 10K 5% 1/10W
R155 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R156 1-216-853-11 METAL CHIP 470K 5% 1/10W
R157 1-216-841-11 METAL CHIP 47K 5% 1/10W
R158 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R159 1-216-833-11 METAL CHIP 10K 5% 1/10W
R160 1-216-821-11 METAL CHIP 1K 5% 1/10W
R161 1-216-833-11 METAL CHIP 10K 5% 1/10W
R162 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R163 1-216-833-11 METAL CHIP 10K 5% 1/10W
R164 1-216-821-11 METAL CHIP 1K 5% 1/10W
R165 1-216-833-11 METAL CHIP 10K 5% 1/10W
R166 1-216-833-11 METAL CHIP 10K 5% 1/10W
R167 1-216-833-11 METAL CHIP 10K 5% 1/10W
R168 1-216-845-11 METAL CHIP 100K 5% 1/10W
R169 1-216-845-11 METAL CHIP 100K 5% 1/10W
R170 1-216-833-11 METAL CHIP 10K 5% 1/10W
R171 1-216-833-11 METAL CHIP 10K 5% 1/10W
R172 1-216-809-11 METAL CHIP 100 5% 1/10W
R173 1-216-833-11 METAL CHIP 10K 5% 1/10W
R174 1-216-833-11 METAL CHIP 10K 5% 1/10W
R175 1-216-833-11 METAL CHIP 10K 5% 1/10W
R176 1-216-849-11 METAL CHIP 220K 5% 1/10W
R177 1-216-849-11 METAL CHIP 220K 5% 1/10W
R194 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(RV55)
R194 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
(RV22)
R195 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(RV55)
R195 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
(RV22)
R197 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R198 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R201 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R202 1-216-833-11 METAL CHIP 10K 5% 1/10W
R203 1-216-833-11 METAL CHIP 10K 5% 1/10W
R204 1-216-833-11 METAL CHIP 10K 5% 1/10W
R205 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R206 1-216-841-11 METAL CHIP 47K 5% 1/10W
R207 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R208 1-216-821-11 METAL CHIP 1K 5% 1/10W
R209 1-216-833-11 METAL CHIP 10K 5% 1/10W
R210 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R211 1-216-821-11 METAL CHIP 1K 5% 1/10W
R212 1-216-833-11 METAL CHIP 10K 5% 1/10W
R213 1-216-821-11 METAL CHIP 1K 5% 1/10W
R214 1-216-821-11 METAL CHIP 1K 5% 1/10W
R216 1-216-806-11 METAL CHIP 56 5% 1/10W
R217 1-216-806-11 METAL CHIP 56 5% 1/10W
0 R218 1-215-891-11 METAL OXIDE 680 5% 2W F
(RV22)
0 R218 1-215-916-00 METAL OXIDE 680 5% 3W F
(RV55)
0 R219 1-215-891-11 METAL OXIDE 680 5% 2W F
(RV22)
0 R219 1-215-916-00 METAL OXIDE 680 5% 3W F
(RV55)
R220 1-216-837-11 METAL CHIP 22K 5% 1/10W
R221 1-216-837-11 METAL CHIP 22K 5% 1/10W
R222 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R223 1-216-864-11 SHORT CHIP 0
R225 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R226 1-216-841-11 METAL CHIP 47K 5% 1/10W
R227 1-216-821-11 METAL CHIP 1K 5% 1/10W
R228 1-216-821-11 METAL CHIP 1K 5% 1/10W
R229 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R230 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R231 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R232 1-216-833-11 METAL CHIP 10K 5% 1/10W
MAIN
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
