HCD-RV222D/RV222DL/RV333D/RV333DL/RV555D
16
2-15. KEY-RIGHT BOARD
2-16. KEY-LEFT BOARD
4 KEY-RIGHT board
1 CN361 (2P)
2 three screws
(+BVTP 2.6 (3CR))
3 four screws
(+BVTP 2.6 (3CR))
4 KEY-LEFT board
1 CN351 (3P)
2 four screws
(+BVTP 2.6 (3CR))
3 three screws
(+BVTP 2.6 (3CR))
