HCD-RV222D/RV222DL/RV333D/RV333DL/RV555D
10
2-3. TUNER ASSY
2-4. LOADING PANEL
1 two screws
(+BVTT 3 u6)
3 tuner assy
2 wire (flat type) (9 core)
(CN081)
1
Turn the pulley to the direction of the arrow.
pulley
Front panel side
CD mechanism deck (CDM74)
3
loading panel
2
Pull-out the disc tray.
