HCD-RV222D/RV222DL/RV333D/RV333DL/RV555D
9
9 case
1 screw
(case 3 TP2)
3 screw
(case 3 TP2)
2 two screws
(case 3 TP2)
4 two screws
(case 3 TP2)
5 seven screws
(+BVTP 3 u8)
6
7
8
Note: Follow the disassembly procedure in the numerical order given.
2-1. CASE
2-2. VOL-LED BOARD
2 two screws
(+BVTP 2.6 (3-CR))
4 VOL-LED board
1 knob (VOL) assy
3 CN302 (2P)
PANEL board
