11
HCD-RV660D/RV990D
2-8. BACK PANEL SECTION
2-7. JACK BOARD
1
two
screws
(+BVTP 2.6
×
8)
4
shield plate
6
JACK board
5
two mic knobs
2
screw
(+BVTT 3
×
6)
3
screw
(+BVTT 3
×
6)
qs
back panel section
5
four
screws
(+BVTT 3
×
6)
8
three
screws
(+BVTP 3
×
8)
6
screw
(+BVTP 3
×
8)
9
two
screws
(+BVTT 3
×
6)
7
two
screws
(+BVTP 3
×
8)
qa
CN704
0
1
CN917
3
CN901
4
CN902
2
CN102
Ver 1.1
