64
HCD-RV660D/RV990D
SECTION 5
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference
number, please include the board.
A-4733-092-A DMB03 BOARD, COMPLETE
(RV990D:EXCEPT TH)
A-4733-130-A DMB03 BOARD, COMPLETE
(RV660D:EXCEPT TH)
A-4748-007-A DMB03 BOARD, COMPLETE (RV990D:TH)
A-4748-069-A DMB03 BOARD, COMPLETE (RV660D:TH)
***********************
< CAPACITOR >
C101 1-126-246-11 ELECT CHIP 220uF 20% 4V
C151 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C204 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C205 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C213 1-126-209-11 ELECT CHIP 100uF 20% 4V
C214 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C215 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C216 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C218 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C220 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C226 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C227 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C229 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C230 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C231 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C232 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C233 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C234 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C235 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C236 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C237 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C238 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C239 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C240 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C241 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C242 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C243 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C244 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C245 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C246 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C247 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C248 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C249 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C250 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C251 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C252 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C253 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C254 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C255 1-117-370-11 CERAMIC CHIP 10uF 10V
C256 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C257 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C258 1-117-370-11 CERAMIC CHIP 10uF 10V
C259 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C260 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C261 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C262 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C263 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C264 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C265 1-117-370-11 CERAMIC CHIP 10uF 10V
C266 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C267 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C268 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C269 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C270 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C271 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C272 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C275 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C281 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C282 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C289 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C302 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
(RV990D)
C303 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
(RV990D)
C304 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
(RV990D)
C305 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
(RV990D)
C306 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
(RV990D)
C307 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
(RV990D)
C308 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C309 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C315 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C316 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C321 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
(RV990D)
C322 1-107-820-11 CERAMIC CHIP 0.1uF 16V
(RV990D)
C323 1-107-820-11 CERAMIC CHIP 0.1uF 16V
(RV990D)
• Abbreviation
E3 : 240 V AC area in E model
E15 : 220 – 240 V AC area in E model
E51 : 220 V AC area in E model
AUS: Australian model
EA : Saudi Arabia model
PH : Philippine model
SP : Singapore model
TH : Thai model
MY : Malaysia model
MX : Mexican model
DMB03
