Sony HCD-RV660D User Manual

67
HCD-RV660D/RV990D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
IC902 8-759-058-64 IC TC7S32FU(TE85R)
IC903 8-759-641-86 IC BR24C16F-E2
IC904 6-702-563-01 IC TC7W74FK-TE85L
IC906 6-700-407-01 IC SM8707GV-G-E2
IC907 8-759-583-47 IC uPC2933T-E2
< JUMPER RESISTOR >
JW392 1-216-864-11 METAL CHIP 0 5% 1/10W
JW601 1-218-990-11 SHORT CHIP 0
JW602 1-218-990-11 SHORT CHIP 0
JW603 1-218-990-11 SHORT CHIP 0
JW604 1-218-990-11 SHORT CHIP 0
JW605 1-218-990-11 SHORT CHIP 0
JW606 1-218-990-11 SHORT CHIP 0
JW607 1-218-990-11 SHORT CHIP 0
JW801 1-218-990-11 SHORT CHIP 0
JW802 1-218-990-11 SHORT CHIP 0
JW803 1-218-990-11 SHORT CHIP 0
JW804 1-218-990-11 SHORT CHIP 0
JW805 1-218-990-11 SHORT CHIP 0
JW806 1-218-990-11 SHORT CHIP 0
L402 1-216-296-11 SHORT CHIP 0
L403 1-216-296-11 SHORT CHIP 0
L404 1-216-296-11 SHORT CHIP 0
L405 1-216-296-11 SHORT CHIP 0
L406 1-216-296-11 SHORT CHIP 0
L412 1-216-296-11 SHORT CHIP 0
L413 1-216-296-11 SHORT CHIP 0
L414 1-216-296-11 SHORT CHIP 0
L415 1-216-296-11 SHORT CHIP 0
L416 1-216-296-11 SHORT CHIP 0
< COIL >
L901 1-412-031-11 INDUCTOR 47uH
< TRANSISTOR >
Q202 8-729-929-26 TRANSISTOR DTC114TE
Q901 8-729-929-26 TRANSISTOR DTC114TE
Q903 8-729-025-28 FET 2SK1828
Q904 8-729-025-28 FET 2SK1828
< RESISTOR >
R10 1-216-801-11 METAL CHIP 22 5% 1/10W
R11 1-216-801-11 METAL CHIP 22 5% 1/10W
R12 1-216-801-11 METAL CHIP 22 5% 1/10W
R13 1-216-801-11 METAL CHIP 22 5% 1/10W
R14 1-216-801-11 METAL CHIP 22 5% 1/10W
R15 1-216-801-11 METAL CHIP 22 5% 1/10W
R207 1-216-864-11 METAL CHIP 0 5% 1/10W
R213 1-216-807-11 METAL CHIP 68 5% 1/10W
R214 1-216-864-11 METAL CHIP 0 5% 1/10W
R215 1-216-864-11 METAL CHIP 0 5% 1/10W
R217 1-216-864-11 METAL CHIP 0 5% 1/10W
R218 1-216-864-11 METAL CHIP 0 5% 1/10W
R219 1-216-864-11 METAL CHIP 0 5% 1/10W
R220 1-216-864-11 METAL CHIP 0 5% 1/10W
R221 1-216-864-11 METAL CHIP 0 5% 1/10W
R222 1-216-864-11 METAL CHIP 0 5% 1/10W
R223 1-216-864-11 METAL CHIP 0 5% 1/10W
R224 1-216-864-11 METAL CHIP 0 5% 1/10W
R227 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R230 1-216-803-11 METAL CHIP 33 5% 1/10W
R231 1-216-803-11 METAL CHIP 33 5% 1/10W
R232 1-216-803-11 METAL CHIP 33 5% 1/10W
R233 1-216-864-11 METAL CHIP 0 5% 1/10W
R234 1-216-833-11 METAL CHIP 10K 5% 1/10W
R239 1-216-809-11 METAL CHIP 100 5% 1/10W
R240 1-216-841-11 METAL CHIP 47K 5% 1/10W
R241 1-216-864-11 METAL CHIP 0 5% 1/10W
R243 1-216-864-11 METAL CHIP 0 5% 1/10W
R244 1-216-821-11 METAL CHIP 1K 5% 1/10W
R245 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R246 1-216-833-11 METAL CHIP 10K 5% 1/10W
R247 1-216-821-11 METAL CHIP 1K 5% 1/10W
R248 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R250 1-216-864-11 METAL CHIP 0 5% 1/10W
R251 1-216-864-11 METAL CHIP 0 5% 1/10W
R253 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R254 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R255 1-216-864-11 METAL CHIP 0 5% 1/10W
R257 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R259 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R260 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R261 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R262 1-216-864-11 METAL CHIP 0 5% 1/10W
R263 1-218-285-11 METAL CHIP 75 5% 1/10W
R264 1-218-285-11 METAL CHIP 75 5% 1/10W
R265 1-218-285-11 METAL CHIP 75 5% 1/10W
R266 1-218-285-11 METAL CHIP 75 5% 1/10W
R267 1-218-285-11 METAL CHIP 75 5% 1/10W
R268 1-216-864-11 METAL CHIP 0 5% 1/10W
R269 1-216-864-11 METAL CHIP 0 5% 1/10W
R270 1-216-864-11 METAL CHIP 0 5% 1/10W
R273 1-216-864-11 METAL CHIP 0 5% 1/10W
R274 1-216-864-11 METAL CHIP 0 5% 1/10W
R275 1-216-864-11 METAL CHIP 0 5% 1/10W
R276 1-216-864-11 METAL CHIP 0 5% 1/10W
R277 1-216-864-11 METAL CHIP 0 5% 1/10W
R278 1-218-285-11 METAL CHIP 75 5% 1/10W
R279 1-218-285-11 METAL CHIP 75 5% 1/10W
R280 1-218-285-11 METAL CHIP 75 5% 1/10W
R281 1-218-285-11 METAL CHIP 75 5% 1/10W
R282 1-218-285-11 METAL CHIP 75 5% 1/10W
R283 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R284 1-218-829-11 METAL CHIP 180 0.5% 1/10W
R288 1-216-864-11 METAL CHIP 0 5% 1/10W
R301 1-216-821-11 METAL CHIP 1K 5% 1/10W
R302 1-216-813-11 METAL CHIP 220 5% 1/10W
(RV990D)
R303 1-216-813-11 METAL CHIP 220 5% 1/10W
(RV990D)
R304 1-216-813-11 METAL CHIP 220 5% 1/10W
(RV990D)
R305 1-216-813-11 METAL CHIP 220 5% 1/10W
(RV990D)
R306 1-216-813-11 METAL CHIP 220 5% 1/10W
(RV990D)
DMB03
