HCD-RV660D/RV990D
1-687-133-11 MOTOR (LD) BOARD
*****************
*************************************************************
1-687-134-11 MOTOR (TB) BOARD
*****************
< CONNECTOR >
CN742 1-784-727-11 CONNECTOR, FFC 5P
*************************************************************
A-4733-288-A PANEL BOARD, COMPLETE (EXCEPT TH)
A-4747-991-A PANEL BOARD, COMPLETE (TH)
**********************
4-248-466-01 HOLDER (FL)
< CAPACITOR >
C100 1-126-382-11 ELECT 100uF 20% 6.3V
C101 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C125 1-126-382-11 ELECT 100uF 20% 6.3V
C131 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C132 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C133 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C137 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C191 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C192 1-126-382-11 ELECT 100uF 20% 6.3V
C193 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C194 1-119-943-11 ELECT 47uF 20% 50V
C195 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C196 1-126-382-11 ELECT 100uF 20% 6.3V
C197 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C198 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C199 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C206 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C207 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C208 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C209 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C225 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C301 1-115-872-11 ELECT 2.2uF 20% 50V
C333 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C334 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C335 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C336 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C337 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C338 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C339 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C340 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C341 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C342 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C343 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C344 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C345 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C353 1-115-872-11 ELECT 2.2uF 20% 50V
< CONNECTOR >
CN101 1-784-731-11 CONNECTOR, FFC 9P
CN102 1-785-319-11 PIN, CONNECTOR (STRAIGHT) 7P
CN103 1-816-422-11 PIN, CONNECTOR 3P
< DIODE >
D101 8-719-988-61 DIODE 1SS355TE-17
D102 8-719-988-61 DIODE 1SS355TE-17
D126 8-719-071-41 LED SELS5923C-TP15 (DVD)
D127 8-719-071-41 LED SELS5923C-TP15 (TUNER/BAND)
D128 8-719-071-41 LED SELS5923C-TP15 (TAPE A/B)
D129 8-719-071-41 LED SELS5923C-TP15 (MD(VIDEO))
D130 8-719-071-41 LED SELS5923C-TP15 (GAME)
D137 6-500-416-01 LED SEL6E10C-S
(MULTI CHANNEL DECODING)
D191 8-719-988-61 DIODE 1SS355TE-17
D192 8-719-071-44 LED SELS5223C-TP15 (?/1)
D193 8-719-988-61 DIODE 1SS355TE-17
D194 8-719-988-61 DIODE 1SS355TE-17
D195 8-719-988-61 DIODE 1SS355TE-17
D196 8-719-988-61 DIODE 1SS355TE-17
D197 8-719-069-56 DIODE UDZS-TE17-6.2B
< FERRITE BEAD >
FB101 1-469-869-21 INDUCTOR (EMI FERRITE)
FB102 1-469-869-21 INDUCTOR (EMI FERRITE)
< FLUORESCENT INDICATOR >
FL1001 1-518-871-21 INDICATOR TUBE, FLUORESCENT
< IC >
IC101 6-802-958-01 IC uPD780232GC-081-8BT
IC102 8-759-584-98 IC SN74AHCT04NSR
< JUMPER RESISTOR >
JR101 1-216-864-11 METAL CHIP 0 5% 1/10W
JR103 1-216-864-11 METAL CHIP 0 5% 1/10W
< TRANSISTOR >
Q126 8-729-907-00 TRANSISTOR DTC114EU
Q127 8-729-907-00 TRANSISTOR DTC114EU
Q128 8-729-907-00 TRANSISTOR DTC114EU
Q129 8-729-907-00 TRANSISTOR DTC114EU
Q130 8-729-907-00 TRANSISTOR DTC114EU
Q131 8-729-907-00 TRANSISTOR DTC114EU
Q132 8-729-907-00 TRANSISTOR DTC114EU
Q133 8-729-907-00 TRANSISTOR DTC114EU
Q134 8-729-907-00 TRANSISTOR DTC114EU
Q135 8-729-907-00 TRANSISTOR DTC114EU
Q136 8-729-907-00 TRANSISTOR DTC114EU
Q137 8-729-907-00 TRANSISTOR DTC114EU
Q168 8-729-028-97 TRANSISTOR DTC114TUA-T106
Q191 8-729-028-73 TRANSISTOR DTA114EUA-T106
< RESISTOR >
R11 1-216-817-11 METAL CHIP 470 5% 1/10W
R12 1-216-819-11 METAL CHIP 680 5% 1/10W
R13 1-216-821-11 METAL CHIP 1K 5% 1/10W
R14 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R15 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R16 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R17 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
PANELMOTOR (TB)MOTOR (LD)
