HCD-RV660D/RV990D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R359 1-249-441-11 CARBON 100K 5% 1/4W
(RV990D)
R360 1-260-076-11 CARBON 10 5% 1/2W F
(RV990D)
R381 1-260-330-11 CARBON 1.5K 5% 1/2W F
(RV990D)
R382 1-260-330-11 CARBON 1.5K 5% 1/2W F
(RV990D)
R383 1-260-330-11 CARBON 1.5K 5% 1/2W F
(RV990D)
R385 1-260-076-11 CARBON 10 5% 1/2W F
(RV990D)
R386 1-260-076-11 CARBON 10 5% 1/2W F
(RV990D)
R390 1-249-429-11 CARBON 10K 5% 1/4W
(RV990D)
R391 1-260-076-11 CARBON 10 5% 1/2W F
(RV990D)
0 R394 1-215-888-00 METAL OXIDE 220 5% 2W F
(RV990D)
R395 1-249-429-11 CARBON 10K 5% 1/4W
(RV990D)
R396 1-249-433-11 CARBON 22K 5% 1/4W
(RV990D)
R397 1-249-417-11 CARBON 1K 5% 1/4W
(RV990D)
R398 1-249-433-11 CARBON 22K 5% 1/4W
(RV990D)
0 R399 1-215-888-00 METAL OXIDE 220 5% 2W F
(RV990D)
< RELAY >
RY381 1-515-920-11 RELAY (RV990D)
RY382 1-515-920-11 RELAY (RV990D)
< THERMISTOR >
TH301 1-807-796-11 THERMISTOR (RV990D)
< TERMINAL BOARD >
TM401 1-694-674-22 TERMINAL BOARD (6P) (SURROUND SPEAKER,
CENTER SPEAKER) (RV990D)
*************************************************************
1-687-669-11 SW BOARD
**********
< SWITCH >
S751 1-786-514-11 SWITCH, LEVER (SLIDE)
(OPEN/CLOSE DETECT)
*************************************************************
A-4733-305-A TRANS BOARD, COMPLETE
(RV990D:EXCEPT E51,AUS,MX,TH)
A-4733-308-A TRANS BOARD, COMPLETE (RV990D:AUS)
A-4733-311-A TRANS BOARD, COMPLETE (RV990D:E51)
A-4733-314-A TRANS BOARD, COMPLETE (MX)
A-4747-999-A TRANS BOARD, COMPLETE (RV990D:TH)
A-4748-005-A TRANS BOARD, COMPLETE (RV660D:TH)
A-4749-048-A TRANS BOARD, COMPLETE
(RV660D:EXCEPT E51,AUS,TH)
A-4749-062-A TRANS BOARD, COMPLETE (RV660D:AUS)
A-4749-072-A TRANS BOARD, COMPLETE (RV660D:E51)
**********************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
0 C271 1-130-777-00 MYLAR 0.1uF 5% 100V
0 C272 1-130-777-00 MYLAR 0.1uF 5% 100V
C371 1-136-153-00 FILM 0.01uF 5% 50V
(RV990D)
C372 1-136-153-00 FILM 0.01uF 5% 50V
(RV990D)
C912 1-126-960-11 ELECT 1uF 20% 50V
C913 1-126-968-11 ELECT 100uF 20% 50V
C915 1-164-159-11 CERAMIC 0.1uF 50V
C918 1-128-576-11 ELECT 100uF 20% 63V
C929 1-126-964-11 ELECT 10uF 20% 50V
C930 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN913 1-564-518-11 PLUG, CONNECTOR 3P (RV990D)
* CN914 1-564-526-11 PLUG, CONNECTOR 11P
* CN915 1-564-519-11 PLUG, CONNECTOR 4P
< DIODE >
0 D271 8-719-510-68 DIODE D5SBA204101
0 D371 8-719-510-68 DIODE D5SBA204101 (RV990D)
0 D911 6-500-522-11 DIODE 10EDB40-TA2B5
D912 8-719-983-76 DIODE MTZJ-T-72-27A
D913 8-719-160-29 DIODE RD6.2F-B2
< TRANSISTOR >
Q971 8-729-048-52 TRANSISTOR 2SA1932(TP)
< RESISTOR >
0 R911 1-219-124-11 FUSIBLE 0.68 5% 1/4W F
R914 1-249-429-11 CARBON 10K 5% 1/4W
R915 1-247-807-31 CARBON 100 5% 1/4W
R916 1-247-807-31 CARBON 100 5% 1/4W
R917 1-249-393-11 CARBON 10 5% 1/4W
R938 1-249-429-11 CARBON 10K 5% 1/4W
*************************************************************
SURROUND AMP SW TRANS
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
