HCD-RV660D/RV990D
Ref. No. Part No. Description Remark
MISCELLANEOUS
***************
61-769-956-11 WIRE (FLAT TYPE) (11 CORE)
56 1-696-656-11 WIRE (FLAT TYPE) (13 CORE)
58 1-769-912-11 WIRE (FLAT TYPE) (9 CORE)
59 1-796-487-31 DECK, MECHANICAL
202 1-757-079-11 WIRE (FLAT TYPE) (17 CORE)
203 1-827-412-11 WIRE (FLAT TYPE) (7 CORE)
204 1-827-411-11 WIRE (FLAT TYPE) (25 CORE) (RV990D)
204 1-827-413-11 WIRE (FLAT TYPE) (13 CORE) (RV660D)
0 259 1-690-608-11 CORD, POWER (AUS)
0 259 1-777-071-83 CORD, POWER (E51,EA,PH,SP,MY)
0 259 1-824-818-11 CORD, POWER (WITH CONNECTOR)
(RV990D:TH)
0 259 1-824-828-11 CORD (WITH PLUG) (RV660D:TH)
0 259 1-827-226-11 CORD, POWER (E3,E15,MX)
302 1-776-182-11 WIRE (FLAT TYPE) (5 CORE)
0 371 1-477-263-11 OPTICAL PICK-UP UNIT
373 1-824-106-12 CABLE, FLEXIBLE FLAT (24 CORE)
374 1-827-410-11 WIRE (FLAT TYPE) (29 CORE)
0 F911 1-533-472-11 FUSE, GLASS TUBE (DIA.5) (T5AL/250V)
(EXCEPT AUS,MX,TH)
0 F912 1-533-472-11 FUSE, GLASS TUBE (DIA.5) (T5AL/250V)
(EXCEPT AUS,MX,TH)
0 F913 1-533-473-11 FUSE, GLASS TUBE (DIA.5) (T6.3AL/250V)
(RV660D:EXCEPT TH)
0 F913 1-576-655-11 FUSE, GLASS TUBE (DIA.5) (T8AL/250V)
(RV990D:EXCEPT TH)
0 F914 1-533-473-11 FUSE, GLASS TUBE (DIA.5) (T6.3AL/250V)
0 F915 1-533-473-11 FUSE, GLASS TUBE (DIA.5) (T6.3AL/250V)
0 F916 1-533-473-11 FUSE, GLASS TUBE (DIA.5) (T6.3AL/250V)
(RV990D)
0 F917 1-533-473-11 FUSE, GLASS TUBE (DIA.5) (T6.3AL/250V)
(RV990D)
0 F918 1-533-471-11 FUSE, GLASS TUBE (DIA.5) (T4AL/250V)
(RV660D:EXCEPT E15,PH)
0 F918 1-533-472-11 FUSE, GLASS TUBE (DIA.5) (T5AL/250V)
(RV660D:E15,PH/RV990D)
0 F919 1-533-471-11 FUSE, GLASS TUBE (DIA.5) (T4AL/250V)
IC921 8-759-518-68 IC PQ12RF21
IC922 8-759-701-59 IC NJM78M09FA
IC923 8-759-701-59 IC NJM78M09FA
IC932 6-703-546-01 IC TA7804LS
IC934 8-759-231-53 IC TA7805S
M741 A-4723-963-A MOTOR ASSY, TABLE (TABLE)
M751 A-4736-655-A MOTOR ASSY, LOADING (LOADING)
M961 1-763-072-11 FAN, DC
RE701 1-477-680-11 ENCODER, ROTARY
(DISC TRAY ADDRESS DETECT)
0 T911 1-437-790-12 TRANSFORMER, POWER (RV660D:EA)
0 T911 1-437-797-12 TRANSFORMER, POWER
(RV660D:EXCEPT EA,TH)
0 T911 1-443-089-11 TRANSFORMER, POWER
(RV660D:TH/RV990D:EXCEPT EA,MX)
0 T911 1-443-090-11 TRANSFORMER, POWER (RV990D:EA,MX)
TM301 1-693-615-21 TUNER PACK (FM/AM) (ANTENNA)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Ver 1.1
