– 121 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
S631 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S632 1-762-875-21 SWITCH, KEYBOARD (CD ^)
S633 1-762-875-21 SWITCH, KEYBOARD (9 TAPE B)
S634 1-762-875-21 SWITCH, KEYBOARD (( TAPE B)
S635 1-762-875-21 SWITCH, KEYBOARD (9 TAPE A)
S636 1-762-875-21 SWITCH, KEYBOARD (( TAPE A)
S652 1-762-875-21 SWITCH, KEYBOARD
(PLAY MODE, DOLBY NR, TUNER MEMORY)
S653 1-762-875-21 SWITCH, KEYBOARD (EDIT, DIRECTION)
S654 1-762-875-21 SWITCH, KEYBOARD (REPEAT, STEREO/MONO)
S655 1-762-875-21 SWITCH, KEYBOARD (PTY) (RX110AV:AEP,UK,G)
S656 1-762-875-21 SWITCH, KEYBOARD (r REC)
S657 1-762-875-21 SWITCH, KEYBOARD (P PAUSE)
S658 1-762-875-21 SWITCH, KEYBOARD (HI-DUB)
S659 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
< VIBRATOR >
X501 1-579-125-11 VIBRATOR, CERAMIC (8MHz)
X601 1-579-125-11 VIBRATOR, CERAMIC (8MHz)
X851 1-767-353-11 VIBRATOR, CERAMIC (4.09MHz)
**************************************************************
* A-4407-272-A POWER BOARD, COMPLETE
**********************
(RX110AV:AEP,UK,G,EE,CIS)
* A-4407-298-A POWER BOARD, COMPLETE (GRX10AV)
**********************
* A-4407-320-A POWER BOARD, COMPLETE (RX110AV:CND)
**********************
< CAPACITOR >
C101 1-130-781-00 FILM 0.22uF 10% 100V
C102 1-130-781-00 FILM 0.22uF 10% 100V
C103 1-164-159-21 CERAMIC 0.1uF 50V
C104 1-164-159-21 CERAMIC 0.1uF 50V
C105 1-126-943-11 ELECT 2200uF 20% 25V
C106 1-162-294-31 CERAMIC 0.001uF 10% 50V
C107 1-162-294-31 CERAMIC 0.001uF 10% 50V
C111 1-126-968-11 ELECT 100uF 20% 50V
C112 1-126-968-11 ELECT 100uF 20% 50V
C113 1-162-294-31 CERAMIC 0.001uF 10% 50V
C114 1-126-967-11 ELECT 47uF 20% 50V
C151 1-128-493-11 ELECT 4700uF 20% 71V
(GRX10AV)
C151 1-104-482-11 ELECT 4700uF 20% 63V
(RX110AV)
C152 1-128-493-11 ELECT 4700uF 20% 71V
(GRX10AV)
C152 1-104-482-11 ELECT 4700uF 20% 63V
(RX110AV)
C201 1-128-582-11 ELECT 10uF 20% 100V
C202 1-162-292-31 CERAMIC 680PF 10% 50V
C203 1-162-286-21 CERAMIC 220PF 10% 50V
C204 1-126-967-11 ELECT 47uF 20% 50V
C205 1-126-967-11 ELECT 47uF 20% 50V
C206 1-128-560-11 ELECT 22uF 20% 100V
C207 1-130-493-00 MYLAR 0.068uF 5% 50V
C208 1-130-493-00 MYLAR 0.068uF 5% 50V
C221 1-162-284-31 CERAMIC 150PF 10% 50V
C222 1-162-284-31 CERAMIC 150PF 10% 50V
C223 1-164-159-21 CERAMIC 0.1uF 50V
C224 1-128-560-11 ELECT 22uF 20% 100V
C225 1-161-494-00 CERAMIC 0.022uF 25V
(RX110AV:AEP,UK,G,EE,CIS)
C228 1-162-284-31 CERAMIC 150PF 10% 50V
C251 1-128-582-11 ELECT 10uF 20% 100V
C252 1-162-292-31 CERAMIC 680PF 10% 50V
C253 1-162-286-21 CERAMIC 220PF 10% 50V
C254 1-126-967-11 ELECT 47uF 20% 50V
C255 1-126-967-11 ELECT 47uF 20% 50V
C256 1-128-560-11 ELECT 22uF 20% 100V
C257 1-130-493-00 MYLAR 0.068uF 5% 50V
C258 1-130-493-00 MYLAR 0.068uF 5% 50V
C301 1-126-934-11 ELECT 220uF 20% 10V
C302 1-126-934-11 ELECT 220uF 20% 10V
C303 1-126-961-99 ELECT 2.2uF 20% 50V
C311 1-126-959-11 ELECT 0.47uF 20% 50V
C312 1-128-573-11 ELECT 470uF 20% 71V
C313 1-128-573-11 ELECT 470uF 20% 71V
C331 1-126-924-11 ELECT 330uF 20% 10V
C401 1-126-963-11 ELECT 4.7uF 20% 50V
C402 1-164-159-21 CERAMIC 0.1uF 50V
(RX110AV:AEP,UK,G,EE,CIS)
C403 1-164-159-21 CERAMIC 0.1uF 50V
(RX110AV:AEP,UK,G,EE,CIS)
C404 1-164-159-21 CERAMIC 0.1uF 50V
(RX110AV:AEP,UK,G,EE,CIS)
C405 1-164-159-21 CERAMIC 0.1uF 50V
(RX110AV:AEP,UK,G,EE,CIS)
C406 1-164-159-21 CERAMIC 0.1uF 50V
(RX110AV:AEP,UK,G,EE,CIS)
C407 1-164-159-21 CERAMIC 0.1uF 50V
(RX110AV:AEP,UK,G,EE,CIS)
C410 1-164-159-21 CERAMIC 0.1uF 50V
(RX110AV:AEP,UK,G,EE,CIS)
C411 1-164-159-21 CERAMIC 0.1uF 50V
(RX110AV:AEP,UK,G,EE,CIS)
C412 1-161-494-00 CERAMIC 0.022uF 25V
C413 1-161-494-00 CERAMIC 0.022uF 25V
C414 1-161-494-00 CERAMIC 0.022uF 25V
C415 1-161-494-00 CERAMIC 0.022uF 25V
< CONNECTOR >
CN201 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
CN202 1-770-724-11 CONNECTOR, BOARD TO BOARD 9P
* CN203 1-573-128-11 PIN, CONNECTOR 5P
< DIODE >
D101 8-719-510-68 DIODE D5SBA20F01
D102 8-719-028-23 DIODE D3SBA20-4101
D103 8-719-200-82 DIODE 11ES2
D104 8-719-200-82 DIODE 11ES2
D105 8-719-991-33 DIODE 1SS133T-77 (RX110AV:AEP,UK,G,EE,CIS)
D111 8-719-200-82 DIODE 11ES2
PANEL POWER
To Next Page
