Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
POWER
D112 8-719-200-82 DIODE 11ES2
D113 8-719-002-60 DIODE UZL-33L
D114 8-719-010-43 DIODE UZ-5.6BSC
D201 8-719-991-33 DIODE 1SS133T-77
D251 8-719-991-33 DIODE 1SS133T-77
D301 8-719-991-33 DIODE 1SS133T-77
D311 8-719-991-33 DIODE 1SS133T-77
D321 8-719-991-33 DIODE 1SS133T-77
D331 8-719-991-33 DIODE 1SS133T-77
D332 8-719-991-33 DIODE 1SS133T-77
D401 8-719-991-33 DIODE 1SS133T-77
D403 8-719-911-19 DIODE 1SS119
D405 8-719-991-33 DIODE 1SS133T-77
D406 8-719-991-33 DIODE 1SS133T-77
D407 8-719-911-19 DIODE 1SS119
D408 8-719-911-19 DIODE 1SS119
< GROUND PLATE >
* EP101 1-537-738-21 TERMINAL, EARTH
* EP201 1-537-738-21 TERMINAL, EARTH
< IC >
IC201 8-749-921-68 IC STK-4231MK2 (GRX10AV)
IC201 8-749-922-65 IC STK-4221MK2 (RX110AV)
< COIL >
L401 1-420-872-00 COIL, AIR-CORE (RX110AV:AEP,UK,G,EE,CIS)
L402 1-420-872-00 COIL, AIR-CORE (RX110AV:AEP,UK,G,EE,CIS)
L403 1-420-872-00 COIL, AIR-CORE (RX110AV:AEP,UK,G,EE,CIS)
L405 1-420-872-00 COIL, AIR-CORE (RX110AV:AEP,UK,G,EE,CIS)
< TRANSISTOR >
Q101 8-729-119-78 TRANSISTOR 2SC403SP-51
(RX110AV:AEP,UK,G,EE,CIS)
Q111 8-729-118-01 TRANSISTOR 2SB1116
Q201 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q251 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q301 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q302 8-729-119-78 TRANSISTOR 2SC403SP-51
Q303 8-729-900-36 TRANSISTOR DTC124ES
Q304 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q305 8-729-900-36 TRANSISTOR DTC124ES
Q306 8-729-119-78 TRANSISTOR 2SC403SP-51
Q307 8-729-119-78 TRANSISTOR 2SC403SP-51
Q321 8-729-119-78 TRANSISTOR 2SC403SP-51
Q322 8-729-900-36 TRANSISTOR DTC124ES
Q401 8-729-040-20 TRANSISTOR RT1P137L-TP
Q402 8-729-900-80 TRANSISTOR DTC114ES
Q404 8-729-040-20 TRANSISTOR RT1P137L-TP
Q405 8-729-904-39 TRANSISTOR DTC114TS
Q406 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
! R101 1-215-886-11 METAL OXIDE 100 5% 2W F
(RX110AV:AEP,UK,G,EE,CIS)
R102 1-249-429-11 CARBON 10K 5% 1/4W
(RX110AV:AEP,UK,G,EE,CIS)
R103 1-249-441-11 CARBON 100K 5% 1/4W
! R111 1-217-637-00 FUSIBLE 1 5% 1/4W F
R112 1-249-417-11 CARBON 1K 5% 1/4W F
R113 1-249-417-11 CARBON 1K 5% 1/4W F
R114 1-247-815-91 CARBON 220 5% 1/4W
R115 1-247-815-91 CARBON 220 5% 1/4W
R116 1-249-425-11 CARBON 4.7K 5% 1/4W F
R201 1-249-417-11 CARBON 1K 5% 1/4W F
R202 1-249-437-11 CARBON 47K 5% 1/4W
R203 1-249-412-11 CARBON 390 5% 1/4W F
R204 1-249-437-11 CARBON 47K 5% 1/4W
R205 1-260-107-11 CARBON 4.7K 5% 1/2W
R206 1-260-107-11 CARBON 4.7K 5% 1/2W
! R207 1-212-881-11 FUSIBLE 100 5% 1/4W F
R208 1-220-893-11 METAL 0.22 10% 5W
R209 1-249-417-11 CARBON 1K 5% 1/4W F
R210 1-249-431-11 CARBON 15K 5% 1/4W
R211 1-249-441-11 CARBON 100K 5% 1/4W
R212 1-260-076-11 CARBON 10 5% 1/2W
! R221 1-217-637-00 FUSIBLE 1 5% 1/4W F
R222 1-260-103-11 CARBON 2.2K 5% 1/2W
R223 1-260-103-11 CARBON 2.2K 5% 1/2W
R224 1-249-425-11 CARBON 4.7K 5% 1/4W F
R251 1-249-417-11 CARBON 1K 5% 1/4W F
R252 1-249-437-11 CARBON 47K 5% 1/4W
R253 1-249-412-11 CARBON 390 5% 1/4W F
R254 1-249-437-11 CARBON 47K 5% 1/4W
R255 1-260-107-11 CARBON 4.7K 5% 1/2W
R256 1-260-107-11 CARBON 4.7K 5% 1/2W
! R257 1-212-881-11 FUSIBLE 100 5% 1/4W F
R258 1-220-893-11 METAL 0.22 10% 5W
R259 1-249-417-11 CARBON 1K 5% 1/4W F
R260 1-249-431-11 CARBON 15K 5% 1/4W
R261 1-249-441-11 CARBON 100K 5% 1/4W
R262 1-260-076-11 CARBON 10 5% 1/2W
R271 1-260-093-11 CARBON 330 5% 1/2W
R272 1-260-093-11 CARBON 330 5% 1/2W
R273 1-260-093-11 CARBON 330 5% 1/2W
R274 1-260-093-11 CARBON 330 5% 1/2W
R301 1-249-429-11 CARBON 10K 5% 1/4W
R302 1-249-425-11 CARBON 4.7K 5% 1/4W F
R303 1-249-429-11 CARBON 10K 5% 1/4W
R304 1-249-429-11 CARBON 10K 5% 1/4W
R305 1-249-425-11 CARBON 4.7K 5% 1/4W F
R306 1-249-441-11 CARBON 100K 5% 1/4W
R308 1-247-903-00 CARBON 1M 5% 1/4W
R310 1-247-903-00 CARBON 1M 5% 1/4W
R311 1-249-441-11 CARBON 100K 5% 1/4W
R312 1-249-419-11 CARBON 1.5K 5% 1/4W F
R313 1-247-863-91 CARBON 22K 5% 1/4W
R314 1-247-863-91 CARBON 22K 5% 1/4W
R315 1-249-439-11 CARBON 68K 5% 1/4W
R316 1-249-437-11 CARBON 47K 5% 1/4W
R321 1-249-440-11 CARBON 82K 5% 1/4W
R322 1-249-441-11 CARBON 100K 5% 1/4W
R323 1-249-441-11 CARBON 100K 5% 1/4W
R324 1-249-441-11 CARBON 100K 5% 1/4W
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
To Next Page
