– 123 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SENSOR
POWER
R331 1-247-890-11 CARBON 300K 5% 1/4W
R332 1-249-429-11 CARBON 10K 5% 1/4W
R333 1-249-431-11 CARBON 15K 5% 1/4W
! R401 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
(GRX10AV)
! R401 1-216-457-00 METAL OXIDE 1.2K 5% 2W F
(RX110AV)
! R403 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
(GRX10AV)
! R403 1-216-457-00 METAL OXIDE 1.2K 5% 2W F
(RX110AV)
R406 1-249-437-11 CARBON 47K 5% 1/4W
R407 1-249-437-11 CARBON 47K 5% 1/4W
R408 1-249-440-11 CARBON 82K 5% 1/4W
R409 1-249-437-11 CARBON 47K 5% 1/4W
R410 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX110AV:AEP,UK,G,EE,CIS)
R411 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX110AV:AEP,UK,G,EE,CIS)
R412 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX110AV:AEP,UK,G,EE,CIS)
R413 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX110AV:AEP,UK,G,EE,CIS)
R414 1-260-076-11 CARBON 10 5% 1/2W
(RX110AV:AEP,UK,G,EE,CIS)
R415 1-260-076-11 CARBON 10 5% 1/2W
(RX110AV:AEP,UK,G,EE,CIS)
R416 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX110AV:AEP,UK,G,EE,CIS)
R417 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX110AV:AEP,UK,G,EE,CIS)
R420 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX110AV:AEP,UK,G,EE,CIS)
R421 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX110AV:AEP,UK,G,EE,CIS)
R422 1-249-393-11 CARBON 10 5% 1/4W F
(RX110AV:AEP,UK,G,EE,CIS)
R424 1-260-076-11 CARBON 10 5% 1/2W
(RX110AV:AEP,UK,G,EE,CIS)
R425 1-260-095-11 CARBON 470 5% 1/2W
R426 1-260-095-11 CARBON 470 5% 1/2W
R427 1-260-095-11 CARBON 470 5% 1/2W
R428 1-260-095-11 CARBON 470 5% 1/2W
R429 1-249-437-11 CARBON 47K 5% 1/4W
R430 1-249-437-11 CARBON 47K 5% 1/4W
< RELAY >
RY101 1-755-195-11 RELAY (RX110AV:AEP,UK,G,EE,CIS)
RY401 1-755-141-11 RELAY
RY403 1-515-920-11 RELAY (24V)
< THERMISTOR >
THP321 1-807-796-11 THERMISTOR
< TERMINAL >
TM401 1-537-842-11 TERMINAL BOARD (FRONT SPEAKER)
TM402 1-537-510-11 TERMINAL BOARD (SPEAKER)(6P)
(SURROUND SPEAKER)
**************************************************************
* 1-658-576-11 SENSOR BOARD
*************
< IC >
IC702 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
IC703 8-749-924-30 IC PHOTO REFLECTOR GP2S28
< RESISTOR >
R701 1-249-416-11 CARBON 820 5% 1/4W F
R702 1-249-407-11 CARBON 150 5% 1/4W F
************************************************************
* A-4407-269-A SURROUND BOARD, COMPLETE
*************************
(RX110AV:AEP,G,UK,EE,CIS)
* A-4407-319-A SURROUND BOARD, COMPLETE (RX110AV:CND)
**************************
* A-4414-862-A SURROUND BOARD, COMPLETE (GRX10AV)
**************************
< CAPACITOR >
C601 1-126-965-11 ELECT 22uF 20% 50V
C602 1-162-292-31 CERAMIC 680PF 10% 50V
C603 1-162-286-21 CERAMIC 220PF 10% 50V
C604 1-126-963-11 ELECT 4.7uF 20% 50V
C605 1-126-967-11 ELECT 47uF 20% 50V
C606 1-126-965-11 ELECT 22uF 20% 50V
C607 1-130-493-00 MYLAR 0.068uF 5% 50V
C608 1-130-493-00 MYLAR 0.068uF 5% 50V
C621 1-162-294-31 CERAMIC 0.001uF 10% 50V
C622 1-104-971-11 ELECT 470uF 20% 50V
C623 1-162-284-31 CERAMIC 150PF 10% 50V
C627 1-162-284-31 CERAMIC 150PF 10% 50V
(RX110AV:AEP,UK,G,EE,CIS)
C628 1-161-494-00 CERAMIC 0.022uF 25V
(RX110AV:AEP,UK,G,EE,CIS)
C651 1-126-965-11 ELECT 22uF 20% 50V
C652 1-162-292-31 CERAMIC 680PF 10% 50V
C653 1-162-286-21 CERAMIC 220PF 10% 50V
C654 1-126-963-11 ELECT 4.7uF 20% 50V
C655 1-126-967-11 ELECT 47uF 20% 50V
C657 1-130-493-00 MYLAR 0.068uF 5% 50V
C658 1-130-493-00 MYLAR 0.068uF 5% 50V
< CONNECTOR >
CN601 1-691-765-11 PLUG(MICROCONNECTOR)3P
CN602 1-691-770-11 PLUG (MICRO CONNECTOR) 8P
< DIODE >
D602 8-719-934-13 DIODE HZS24-1L (RX110AV)
D602 8-719-934-17 DIODE HZS27-1L (GRX10AV)
D604 8-719-911-19 DIODE 1SS119
< EARTH TERMINAL >
* EP601 1-537-738-21 TERMINAL, EARTH (RX110AV:AEP,UK,G,EE,CIS)
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
SURROUND
To Next Page
