– 124 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
TCB
* EP602 1-537-738-21 TERMINAL, EARTH (RX110AV:AEP,UK,G,EE,CIS)
< IC >
IC601 8-749-900-96 IC STK-4142MK2
< TRANSISTOR >
Q601 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q604 8-729-119-78 TRANSISTOR 2SC403SP-51
Q651 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R601 1-249-417-11 CARBON 1K 5% 1/4W F
R602 1-249-437-11 CARBON 47K 5% 1/4W
R603 1-249-413-11 CARBON 470 5% 1/4W F
R604 1-249-437-11 CARBON 47K 5% 1/4W
R605 1-260-103-11 CARBON 2.2K 5% 1/2W
R606 1-260-103-11 CARBON 2.2K 5% 1/2W
! R607 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R608 1-217-151-00 METAL 0.22 10% 2W
R608 1-220-755-11 METAL 0.22 10% 2W
R609 1-249-441-11 CARBON 100K 5% 1/4W
R610 1-249-441-11 CARBON 100K 5% 1/4W
R611 1-249-441-11 CARBON 100K 5% 1/4W
R612 1-260-076-11 CARBON 10 5% 1/2W
R621 1-260-109-11 CARBON 6.8K 5% 1/2W F
! R622 1-217-881-11 FUSIBLE 100 5% 1/4W F
R629 1-249-429-11 CARBON 10K 5% 1/4W
R651 1-249-417-11 CARBON 1K 5% 1/4W F
R652 1-249-437-11 CARBON 47K 5% 1/4W
R653 1-249-415-11 CARBON 680 5% 1/4W F
R654 1-249-437-11 CARBON 47K 5% 1/4W
R655 1-260-103-11 CARBON 2.2K 5% 1/2W
R656 1-260-103-11 CARBON 2.2K 5% 1/2W
R658 1-217-151-00 METAL 0.22 10% 2W
! R658 1-220-755-11 METAL 0.22 10% 2W
R659 1-249-441-11 CARBON 100K 5% 1/4W
R660 1-249-441-11 CARBON 100K 5% 1/4W
R661 1-249-441-11 CARBON 100K 5% 1/4W
R662 1-260-076-11 CARBON 10 5% 1/2W
**************************************************************
* A-4303-588-A TCB BOARD, COMPLETE (EE,CIS)
***************************
< CAPACITOR >
C1 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C2 1-126-967-11 ELECT 47uF 20% 16V
C3 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C5 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C6 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C7 1-101-004-00 CERAMIC 0.01uF 50V
C8 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C9 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C10 1-162-306-11 CERAMIC CHIP 0.01uF 30% 16V
C16 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C19 1-163-249-11 CERAMIC CHIP 82PF 5% 50V
C21 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C22 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C23 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C24 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C26 1-126-967-11 ELECT 47uF 20% 16V
C28 1-126-967-11 ELECT 47uF 20% 16V
C29 1-162-306-11 CERAMIC 0.01uF 30% 16V
C30 1-126-961-11 ELECT 2.2uF 20% 50V
C31 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C32 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C33 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C34 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C35 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C36 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C37 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C39 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C40 1-126-967-11 ELECT 47uF 20% 16V
C41 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C42 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C43 1-163-031-91 CERAMIC CHIP 0.01uF 50V
C44 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C45 1-163-077-00 CERAMIC CHIP 0.1uF 50V
C46 1-126-967-11 ELECT 47uF 20% 16V
C47 1-126-301-11 ELECT 1.0uF 20% 50V
C48 1-163-059-00 CERAMIC CHIP 0.01uF 50V
C49 1-126-964-11 ELECT 10uF 20% 50V
C50 1-126-960-11 ELECT 1.0uF 20% 50V
C51 1-126-959-11 ELECT 0.47uF 20% 50V
C52 1-126-960-11 ELECT 1.0uF 20% 50V
C53 1-126-964-11 ELECT 10uF 20% 50V
C54 1-104-396-11 ELECT 10uF 20% 16V
C55 1-104-396-11 ELECT 10uF 20% 16V
C56 1-104-396-11 ELECT 10uF 20% 16V
C57 1-163-017-00 CERAMIC CHIP 0.0047uF 10% 50V
C58 1-163-017-00 CERAMIC CHIP 0.0047uF 10% 50V
C59 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C60 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C61 1-126-301-11 ELECT 1.0uF 20% 50V
C62 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C63 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C64 1-126-967-11 ELECT 47uF 20% 16V
C65 1-126-967-11 ELECT 47uF 20% 16V
C66 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C67 1-126-162-11 ELECT 3.3uF 20% 50V
C68 1-163-031-11 CERAMIC 0.01uF 50V
C69 1-126-967-11 ELECT 47uF 20% 16V
C71 1-162-306-11 CERAMIC 0.01uF 30% 16V
C72 1-126-967-11 ELECT 47uF 20% 16V
C73 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C74 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C1701 1-162-294-31 CERAMIC CHIP 0.001uF 10% 50V
C1702 1-130-014-00 FILM 470PF 5% 50V
C1703 1-126-959-11 ELECT 0.47uF 20% 50V
C1704 1-126-959-11 ELECT 0.47uF 20% 50V
C1705 1-163-035-00 CERAMIC CHIP 0.047uF 50V
C1706 1-126-960-11 ELECT 1.0uF 20% 50V
C1707 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
SURROUND
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
To Next Page
