– 128 –
Ref. No. Part No. Description Remark
R7 1-216-037-00 METAL CHIP 330 5% 1/10W
R8 1-216-037-00 METAL CHIP 330 5% 1/10W
R9 1-216-081-00 METAL CHIP 22K 5% 1/10W
R10 1-216-037-00 METAL CHIP 330 5% 1/10W
R11 1-216-081-00 METAL CHIP 22K 5% 1/10W
R12 1-216-037-00 METAL CHIP 330 5% 1/10W
R13 1-216-037-00 METAL CHIP 330 5% 1/10W
R14 1-216-081-00 METAL CHIP 22K 5% 1/10W
R18 1-216-073-00 METAL CHIP 10K 5% 1/10W
R19 1-216-073-00 METAL CHIP 10K 5% 1/10W
R21 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R22 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R23 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R24 1-216-025-91 METAL CHIP 100 5% 1/10W
R25 1-249-417-11 CARBON 1K 5% 1/4W F
R26 1-249-437-11 CARBON 47K 5% 1/4W
R27 1-249-429-11 CARBON 10K 5% 1/4W
R28 1-249-417-11 CARBON 1K 5% 1/4W F
R29 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R30 1-216-186-00 METAL CHIP 330 5% 1/8W
R31 1-216-025-91 METAL CHIP 100 5% 1/10W
R32 1-249-425-11 CARBON 4.7K 5% 1/4W F
R33 1-249-425-11 CARBON 4.7K 5% 1/4W F
R34 1-249-425-11 CARBON 4.7K 5% 1/10W
R35 1-216-214-00 METAL CHIP 4.7K 5% 1/8W
R36 1-216-025-91 METAL CHIP 100 5% 1/10W
R37 1-216-073-00 METAL CHIP 10K 5% 1/10W
R38 1-216-089-91 METAL CHIP 47K 5% 1/10W
R39 1-249-429-11 CARBON 10K 5% 1/4W
R41 1-216-013-00 METAL CHIP 33 5% 1/10W
R42 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R43 1-216-037-00 METAL CHIP 330 5% 1/10W
R44 1-216-001-00 METAL CHIP 10 5% 1/10W
R45 1-247-843-11 CARBON 3.3K 5% 1/4W F
R46 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R47 1-216-097-91 METAL CHIP 100K 5% 1/10W
R48 1-249-417-11 CARBON 1K 5% 1/4W F
R49 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R50 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R51 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R52 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R53 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R54 1-216-073-00 METAL CHIP 10K 5% 1/10W
R55 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R57 1-216-162-00 METAL CHIP 33 5% 1/8W
R58 1-216-013-00 METAL CHIP 33 5% 1/10W
R91 1-216-295-91 METAL CHIP 0 5% 1/10W
R92 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1751 1-247-807-31 CARBON 100 5% 1/4W
R1752 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1753 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R1754 1-216-097-91 METAL CHIP 100K 5% 1/10W
R1755 1-216-097-91 METAL CHIP 100K 5% 1/10W
R1756 1-249-401-11 CARBON 47 5% 1/4W F
R1757 1-216-295-91 METAL CHIP 0 5% 1/10W
< VARIABLE RESISTOR >
RV41 1-238-600-11 RES, ADJ, CARBON 10K
RV42 1-238-600-11 RES, ADJ, CARBON 10K
< TERMINAL >
TM1 1-537-488-11 TERMINAL BOARD (ANT) (ANTENNA)
< VIBRATOR >
X21 1-760-549-11 VIBRATOR, CRYSTAL (4.5MHz)
X41 1-767-825-21 FILTER, CERAMIC (10.7MHz)
X42 1-527-981-00 FILTER, CERAMIC (450KHz)
X1751 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz)
************************************************************
* 1-668-274-11 TRANSFORMER BOARD
*******************
< CONNECTOR >
* CN501 1-564-527-11 PLUG, CONNECTOR 12P
CN502 1-774-108-11 PIN, CONNECTOR (PC BOARD) 2P
< FUSE >
! F501 1-532-505-31 FUSE T5AL/250V (GRX10AV:E2,E3,SP,MY,HK,EA)
! F504 1-532-506-31 FUSE T6.3A/250V (EXCEPT RX110AV:CND)
! F504 1-533-310-11 FUSE, GLASS TUBE 6.3A/125V (RX110AV:CND)
! F505 1-532-506-31 FUSE T6.3A/250V (EXCEPT RX110AV:CND)
! F505 1-533-310-11 FUSE, GLASS TUBE 6.3A/125V (RX110AV:CND)
< FUSE HOLDER >
FH501 1-533-233-21 HOLDER, FUSE (GRX10AV:E2,E3,EA,SP,MY,HK)
FH502 1-533-233-21 HOLDER, FUSE (GRX10AV:E2,E3,EA,SP,MY,HK)
FH507 1-533-233-21 HOLDER, FUSE
FH508 1-533-233-21 HOLDER, FUSE
FH509 1-533-233-21 HOLDER, FUSE
FH510 1-533-233-21 HOLDER, FUSE
< RESISTOR >
! R501 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R502 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R503 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R504 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R505 1-202-725-00 SOLID 3.3M 10% 1/2W
(RX110AV:CND)
< SWITCH >
! S501 1-771-291-11 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(GRX10AV:E2,E3,EA,SP,MY,HK)
< TRANSFORMER >
! T501 1-431-709-11 TRANSFORMER, POWER
(GRX10AV:E2,EA,SP,MY,HK,AUS)
! T501 1-431-710-11 TRANSFORMER, POWER
(RX110AV:AEP,UK,G,EE,CIS)
! T501 1-431-711-21 TRANSFORMER, POWER (GRX10AV:TH)
! T501 1-431-712-11 TRANSFORMER, POWER (RX110AV:CND)
! T501 1-431-769-11 TRANSFORMER, POWER (GRX10AV:E3)
**************************************************************
Ref. No. Part No. Description Remark
TRANSFORMER
TCB
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
To Next Page
