– 129 –
MISCELLANEOUS
**************
6 1-693-419-11 TUNER (FM/AM) (CND)
6 1-693-420-11 TUNER (FM/AM) (E2,TH,AUS)
6 1-693-421-11 TUNER (FM/AM) (E3,EA,SP,MY,HK)
8 1-769-977-11 WIRE (FLAT TYPE) (13 CORE)(150mm)
8 1-773-009-11 WIRE (FLAT TYPE) (15 CORE)(150mm)
54 1-773-041-11 WIRE (FLAT TYPE) (17 CORE)
! 58 1-569-007-11 ADAPTOR, CONVERSION 2P (E3)
! 58 1-569-008-11 ADAPTOR, CONVERSION 2P (EA,SP,MY)
! 58 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK,HK)
! 59 1-558-943-41 CORD, POWER (E2,E3)
! 59 1-575-042-21 CORD, POWER (CND)
! 59 1-575-651-21 CORD, POWER (AEP,G,UK,EE,CIS,EA,SP,MY,HK)
! 59 1-696-845-31 CORD, POWER (AUS)
! 59 1-751-326-21 CORD, POWER (TH)
60 1-773-011-11 WIRE (FLAT TYPE) (15 CORE)
61 1-773-112-11 WIRE (FLAT TYPE) (19 CORE)
121 1-769-974-11 WIRE (FLAT TYPE) (13 CORE)
130 1-773-109-11 WIRE (FLAT TYPE) (19 CORE)(110mm)
257 1-452-879-11 MAGNET (CDM38L-5BD29AL)
257 1-452-925-21 MAGNET ASSY (CDM38LH-5BD29AL)
258 1-776-042-11 WIRE (FLAT TYPE) (8CORE)
HP101 A-2056-681-A DECK (A) ASSY, HEAD (230AWR1)
HP101 A-2056-683-A DECK (A) ASSY, HEAD (230PWR1)
HRPE101 A-2056-682-A DECK (B) ASSY, HEAD (230AWR1)
HRPE101 A-2056-684-A DECK (B) ASSY, HEAD (230PWR1)
M1 A-2004-628-A MOTOR ASSY, CAPSTAN
M701 A-4672-004-A MOTOR ASSY (TURN)
M801 A-4672-004-A MOTOR ASSY (SLIDE)
M901 1-698-792-11 FAN, DC (RX110AV)
M901 1-763-048-21 FAN, D.C. (GRX10AV)
ND601 1-517-731-21 INDICATOR TUBE, FLUORESCENT
S811 1-473-335-11 ENCODER,ROTARY (BU,TRAY ADDRESS DET)
! T501 1-431-709-11 TRANSFORMER, POWER
(GRX10AV:E2,EA,SP,MY,HK,AUS)
! T501 1-431-710-11 TRANSFORMER, POWER
(RX110AV:AEP,G,UK,EE,CIS)
! T501 1-431-711-21 TRANSFORMER, POWER (GRX10AV:TH)
! T501 1-431-712-11 TRANSFORMER, POWER (RX110AV:CND)
! T501 1-431-769-11 TRANSFORMER, POWER (GRX10AV:E3)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-872-09 SCREW +BVTT 3X8 (S)
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#5 7-685-871-01 SCREW +BVTT 3X6 (S)
#6 7-685-880-09 SCREW +BVTT 4X6 (S)(GRX10AV)
#6 7-685-871-01 SCREW +BVTT 3X6 (S)(RX110AV)
#7 7-685-851-04 SCREW +BVTT 2X4 (S)
#8 7-621-775-10 SCREW +B 2.6X4
#9 7-621-255-15 SCREW +P 2X3
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
#10 7-685-850-04 SCREW +BVTT 2X3 (S)
#11 7-628-254-15 SCREW +PS 2.6X6
#12 7-628-254-50 SCREW +PS 2.6X16
To Next Page
