– 90 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
PANEL
R911 1-249-409-11 CARBON 220 5% 1/4W F
R920 1-249-383-11 CARBON 1.5 5% 1/6W F
R921 1-249-383-11 CARBON 1.5 5% 1/6W F
R931 1-249-429-11 CARBON 10K 5% 1/4W
< VARIABLE RESISTOR >
RV301 1-238-600-11 RES, ADJ, CARBON 10K
RV351 1-238-600-11 RES, ADJ, CARBON 10K
< RELAY >
RY401 1-515-920-11 RELAY (GRX80:EA4,TH)
RY401 1-755-168-11 RELAY
(GRX80:E2,E3,EA3,SP,AR,TW,MX,AUS/RXD8/RXD8S)
< THERMISTOR >
TH801 1-807-796-11 THERMISTOR
< TERMINAL >
TM401 1-537-240-31 TERMINAL BOARD (CHECKER PIN)(SPEAKER)
(GRX80)
TM401 1-694-302-11 TERMINAL BOARD (CHECKER PIN)
(RXD8/RXD8S)
TM402 1-537-240-31 TERMINAL BOARD (CHECKER PIN)
(SURROUND SPEAKER)
< VIBRATOR >
X601 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X613 1-781-107-21 VIBRATOR, SERAMIC (16MHz)
**************************************************************
* 1-658-578-11 MOTOR (SLIDE) BOARD
*******************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 20% 16V
C804 1-162-306-11 CERAMIC 0.01uF 20% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-921-48 DIODE MTZJ-T-72-5.6C (Malaysia PRODUCT)
D801 8-719-109-89 DIODE RD5.6ESB2 (Indonesia PRODUCT)
D804 8-719-911-19 DIODE 1SS119
D805 8-719-911-19 DIODE 1SS119
< IC >
IC801 8-759-274-09 IC BA6286N
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W F
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY (OPEN/CLOSE)
**************************************************************
* 1-658-577-11 MOTOR (TURN) BOARD
******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 20% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-983-66 DIODE MTZJ-T-72-3.6B (Malaysia PRODUCT)
D701 8-719-109-69 DIODE RD3.6ES-B2 (Indonesia PRODUCT)
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R706 1-249-411-11 CARBON 330 5% 1/4W
R707 1-249-401-11 CARBON 47 5% 1/4W F
**************************************************************
* A-4417-643-A PANEL BOARD, COMPLETE (RXD8/RXD8S)
*********************
* A-4417-650-A PANEL BOARD, COMPLETE (GRX80:EA3)
*********************
* A-4417-660-A PANEL BOARD, COMPLETE
*********************
(EXCEPT GRX80:EA3/RXD8/RXD8S)
* 4-214-439-11 HOLDER, FL TUBE
< CAPACITOR >
C601 1-124-589-11 ELECT 47uF 20% 16V
C602 1-126-163-11 ELECT 4.7uF 20% 50V
C603 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C604 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C605 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C608 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C610 1-124-589-11 ELECT 47uF 20% 16V
C611 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C612 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C614 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C615 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C616 1-126-157-11 ELECT 10uF 20% 16V
C617 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C618 1-126-157-11 ELECT 10uF 20% 16V
C619 1-126-157-11 ELECT 10uF 20% 16V
C620 1-126-163-11 ELECT 4.7uF 20% 50V
C621 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C622 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C625 1-126-157-11 ELECT 10uF 20% 16V
C628 1-126-163-11 ELECT 4.7uF 20% 50V
MOTOR (SLIDE) MOTOR (TURN)
