– 91 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
PANEL
C629 1-124-589-11 ELECT 47uF 20% 16V
C630 1-126-157-11 ELECT 10uF 20% 16V
C631 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C632 1-124-589-11 ELECT 47uF 20% 16V
C633 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C634 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C701 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(RXD8/RXD8S)
C702 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(RXD8/RXD8S)
C703 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C711 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(GRX80:EA3)
C712 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
(GRX80:EA3)
C713 1-126-160-11 ELECT 1uF 20% 50V
(GRX80:EA3)
C714 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
(GRX80:EA3)
C715 1-124-465-00 ELECT 0.47uF 20% 50V
(GRX80:EA3)
C716 1-124-465-00 ELECT 0.47uF 20% 50V
(GRX80:EA3)
C717 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V
(GRX80:EA3)
C718 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(GRX80:EA3)
C719 1-126-160-11 ELECT 1uF 20% 50V
(GRX80:EA3)
C720 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
(GRX80:EA3)
C721 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
(GRX80:EA3)
C722 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
(GRX80:EA3)
C723 1-124-589-11 ELECT 47uF 20% 16V
(GRX80:EA3)
C724 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(GRX80:EA3)
C725 1-124-589-11 ELECT 47uF 20% 16V
(GRX80:EA3)
C731 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C732 1-124-257-00 ELECT 2.2uF 20% 50V
C733 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C734 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C735 1-126-157-11 ELECT 10uF 20% 16V
C736 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C737 1-124-463-00 ELECT 0.1uF 20% 50V
C738 1-124-257-00 ELECT 2.2uF 20% 50V
(GRX80:EA3)
C739 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C741 1-126-157-11 ELECT 10uF 20% 16V
C742 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C743 1-124-257-00 ELECT 2.2uF 20% 50V
C747 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C782 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C783 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C851 1-163-038-91 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
* CN601 1-568-867-11 SOCKET, CONNECTOR 25P
< DIODE >
D601 8-719-058-24 DIODE RB501V-40TE-17
D608 8-719-074-27 DIODE SELUIE10CXM-LC(LEFT)
D609 8-719-074-24 DIODE SELUD10CXM-LC (RIGHT)
D611 8-719-071-41 DIODE SELS5923C-TP15 (SYNC EQ)
D612 8-719-071-44 DIODE SELS5223C-TP15 (EFFECT)
D613 8-719-071-41 DIODE SELS5923C-TP15 (SYNC BASS L)
D614 8-719-071-41 DIODE SELS5923C-TP15 (SYNC BASS H)
D615 8-719-063-93 DIODE SLR325VC-N-T32 (NON STOP)
D619 8-719-056-13 DIODE SML79423C-TP15 (^)
D620 8-719-073-47 DIODE SML72923C-TP15 (PAUSE/START, REC
D621 8-719-056-13 DIODE SML79423C-TP15 (AUTO BPM)
D622 8-719-057-97 DIODE SEL5923A-TP15 (+/))
D623 8-719-057-97 DIODE SEL5923A-TP15 (-/0)
D624 8-719-063-93 DIODE SLR325VC-N-T32 (JOG)
D625 8-719-063-93 DIODE SLR325VC-N-T32 (ENTER/NEXT)
D626 8-719-057-97 DIODE SEL5923A-TP15 (GROOVE)
D627 8-719-057-97 DIODE SEL5923A-TP15 (PAD A)
D628 8-719-057-97 DIODE SEL5923A-TP15 (PAD B)
D629 8-719-057-97 DIODE SEL5923A-TP15 (BEAT ON/OFF)
D630 8-719-057-97 DIODE SEL5923A-TP15 (BEAT JAM)
D631 8-719-058-03 DIODE SEL5423E-TP15 (9 (B DECK))
D632 8-719-058-03 DIODE SEL5423E-TP15 (( (B DECK))
D633 8-719-058-03 DIODE SEL5423E-TP15 (9 (A DECK))
D634 8-719-058-03 DIODE SEL5423E-TP15 (( (A DECK))
D635 8-719-063-93 DIODE SLR325VC-N-T32 (TIMER SELECT)
D701 8-719-976-99 DIODE DTZ5.1B (GRX80:EA3)
< GROUND PLATE >
EP601 1-537-770-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB601 1-414-234-22 INDUCTOR CHIP 0UH
FB602 1-414-234-22 INDUCTOR CHIP 0UH
< FLUORESCENT INDICATOR >
FL601 1-517-831-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 8-759-571-93 IC TMP88CS76F-6000
IC602 8-749-011-05 IC GP1U28X
IC603 8-759-083-77 IC BA3830F
IC604 8-759-342-19 IC NJU3716M-T2
IC605 8-759-577-80 IC MSM6654A-540GS-K
IC711 8-759-496-41 IC M65850FP-E1 (GRX80:EA3)
IC712 8-759-636-55 IC M5218AFP
< JACK >
J701 1-785-569-11 JACK (SMALL TYPE)(HEADPHONES)
J711 1-785-569-11 JACK (SMALL TYPE)(MIC 1)
