HCD-S400
SECTION 2
GENERAL
This section is extracted
from instruction manual.
Index to Parts and Controls
For more information, refer to the pages indicated in parentheses.
Front Panel
POWER switch/indicator (30)
Disc tray (30)
OPEN/CLOSE (30)
Front panel display (10)
./>, PREV/NEXT, PRESET +/–
(28, 31)
H (play) (30)
X (pause) (31)
PHONES jack (30)
VOLUME control (30)
SOUND FIELD +/– (46)
DISPLAY (46, 59)
BAND (28)
FUNCTION (58)
(remote sensor) (16)
A
x (stop) (30)
AM antenna (19)
AUDIO 1 jacks (21)
AUDIO 2 jacks (21)
DIGITAL IN (OPTICAL) jack (22)
MONITOR OUT jack (21)
SPEAKER jacks (17)
FM 75 COAXIAL antenna jack (20)
Rear Panel
AM
COAXIAL
FM
75
L
R
L
R
OPTICAL
DIGITAL IN VIDEO OUTAUDIO OUT
AUDIO IN AUDIO IN
SPEAKER
FRONT R
REAR R
CENTER
WOOFER
FRONT L
REAR L
IMPEDANCE USE WOOFER: 3 EXCEPT WOOFER: 6
A
N
T
E
N
N
A
AUDIO 1 AUDIO 2
MONITOR
OUT
Ω
