HCD-S400
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
•Refer to servicing notes (page 3) for
discrimination of TYPE A/B.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board
name.
A-4728-790-A AMP BOARD, COMPLETE
******************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C300 1-115-819-11 ELECT 2200uF 20% 35V
C301 1-126-965-91 ELECT 22uF 20% 50V
C302 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C303 1-136-157-00 FILM 0.022uF 5% 50V
C304 1-136-157-00 FILM 0.022uF 5% 50V
C305 1-136-165-00 FILM 0.1uF 5% 50V
C306 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C307 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C308 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C309 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C310 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C311 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C312 1-104-665-11 ELECT 100uF 20% 10V
C313 1-136-165-00 FILM 0.1uF 5% 50V
C316 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C317 1-126-948-11 ELECT 100uF 20% 35V
C318 1-104-665-11 ELECT 100uF 20% 10V
C319 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C320 1-104-665-11 ELECT 100uF 20% 10V
C323 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C324 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C325 1-104-665-11 ELECT 100uF 20% 10V
C326 1-126-947-11 ELECT 47uF 20% 10V
C327 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C328 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C329 1-126-934-11 ELECT 220uF 20% 10V
C330 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C331 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C332 1-136-157-00 FILM 0.022uF 5% 50V
C333 1-136-157-00 FILM 0.022uF 5% 50V
C334 1-136-165-00 FILM 0.1uF 5% 50V
C335 1-136-165-00 FILM 0.1uF 5% 50V
C336 1-104-665-11 ELECT 100uF 20% 10V
C337 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C341 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C342 1-126-948-11 ELECT 100uF 20% 35V
C343 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C344 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C345 1-104-665-11 ELECT 100uF 20% 10V
C348 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C349 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C350 1-104-665-11 ELECT 100uF 20% 10V
C351 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C352 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C353 1-136-157-00 FILM 0.022uF 5% 50V
C354 1-136-157-00 FILM 0.022uF 5% 50V
C355 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C356 1-136-165-00 FILM 0.1uF 5% 50V
C357 1-136-165-00 FILM 0.1uF 5% 50V
C358 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C359 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C362 1-104-665-11 ELECT 100uF 20% 10V
C363 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C364 1-126-948-11 ELECT 100uF 20% 35V
C365 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C368 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C372 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C373 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C374 1-136-157-00 FILM 0.022uF 5% 50V
C375 1-136-157-00 FILM 0.022uF 5% 50V
C376 1-136-165-00 FILM 0.1uF 5% 50V
C377 1-136-165-00 FILM 0.1uF 5% 50V
C378 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C381 1-104-665-11 ELECT 100uF 20% 10V
C382 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C383 1-126-948-11 ELECT 100uF 20% 35V
C384 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C387 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C388 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C389 1-104-665-11 ELECT 100uF 20% 10V
C390 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C391 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C392 1-104-665-11 ELECT 100uF 20% 10V
C393 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C394 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C395 1-136-157-00 FILM 0.022uF 5% 50V
C396 1-136-157-00 FILM 0.022uF 5% 50V
C397 1-136-165-00 FILM 0.1uF 5% 50V
C398 1-136-165-00 FILM 0.1uF 5% 50V
C399 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C402 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C403 1-126-948-11 ELECT 100uF 20% 35V
C404 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C405 1-104-665-11 ELECT 100uF 20% 10V
C408 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C409 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C410 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C411 1-136-157-00 FILM 0.022uF 5% 50V
