Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-S400
C412 1-136-157-00 FILM 0.022uF 5% 50V
C413 1-136-165-00 FILM 0.1uF 5% 50V
C414 1-136-165-00 FILM 0.1uF 5% 50V
C415 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C416 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C419 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C420 1-126-948-11 ELECT 100uF 20% 35V
C421 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C422 1-104-665-11 ELECT 100uF 20% 10V
C425 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C432 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C433 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C434 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C441 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C442 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C443 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C451 1-131-704-11 FILM 1uF 5% 50V
C452 1-131-704-11 FILM 1uF 5% 50V
C453 1-131-704-11 FILM 1uF 5% 50V
C454 1-131-704-11 FILM 1uF 5% 50V
C455 1-131-704-11 FILM 1uF 5% 50V
C456 1-131-704-11 FILM 1uF 5% 50V
C457 1-131-704-11 FILM 1uF 5% 50V
C458 1-131-704-11 FILM 1uF 5% 50V
C459 1-131-704-11 FILM 1uF 5% 50V
C460 1-131-704-11 FILM 1uF 5% 50V
C461 1-131-704-11 FILM 1uF 5% 50V
C462 1-131-704-11 FILM 1uF 5% 50V
C474 1-126-934-11 ELECT 220uF 20% 16V
C484 1-126-934-11 ELECT 220uF 20% 16V
< CONNECTOR >
CN301 1-779-280-11 CONNECTOR, FFC(LIF(NON-ZIF))12P
CN305 1-793-600-11 CONNECTOR, FFC/FPC (ZIF) 17P
* CN309 1-506-987-11 PIN, CONNECTOR (PC BOARD) 5P
< DIODE >
D330 6-500-131-01 DIODE LI116
D331 6-500-131-01 DIODE LI116
D332 6-500-131-01 DIODE LI116
D333 6-500-131-01 DIODE LI116
D334 6-500-131-01 DIODE LI116
D335 6-500-131-01 DIODE LI116
D340 6-500-131-01 DIODE LI116
D341 6-500-131-01 DIODE LI116
D342 6-500-131-01 DIODE LI116
D343 6-500-131-01 DIODE LI116
D344 6-500-131-01 DIODE LI116
D345 6-500-131-01 DIODE LI116
D351 8-719-404-50 DIODE MA111-TX
D370 6-500-055-01 DIODE P6SMB33AT3
D371 6-500-055-01 DIODE P6SMB33AT3
D372 6-500-055-01 DIODE P6SMB33AT3
D373 6-500-055-01 DIODE P6SMB33AT3
D374 6-500-055-01 DIODE P6SMB33AT3
D375 6-500-055-01 DIODE P6SMB33AT3
D380 6-500-055-01 DIODE P6SMB33AT3
D381 6-500-055-01 DIODE P6SMB33AT3
D382 6-500-055-01 DIODE P6SMB33AT3
D383 6-500-055-01 DIODE P6SMB33AT3
D384 6-500-055-01 DIODE P6SMB33AT3
D385 6-500-055-01 DIODE P6SMB33AT3
< EARTH TERMINAL >
* EB301 1-537-738-21 TERMINAL, EARTH
< FERRITE BEAD >
FB300 1-469-760-21 INDUCTOR 0UH
FB301 1-469-760-21 INDUCTOR 0UH
FB303 1-400-160-51 INDUCTOR 0UH
FB304 1-469-760-21 INDUCTOR 0UH
FB307 1-469-760-21 INDUCTOR 0UH
FB308 1-469-760-21 INDUCTOR 0UH
FB309 1-400-160-51 INDUCTOR 0UH
FB312 1-400-160-51 INDUCTOR 0UH
FB313 1-400-160-51 INDUCTOR 0UH
FB314 1-469-760-21 INDUCTOR 0UH
FB315 1-469-760-21 INDUCTOR 0UH
FB318 1-400-160-51 INDUCTOR 0UH
FB320 1-400-160-51 INDUCTOR 0UH
FB350 1-216-295-91 SHORT CHIP 0
FB365 1-216-295-91 SHORT CHIP 0
< IC >
IC300 8-759-834-29 IC MC74VHC1G04DFT1
IC301 6-701-741-01 IC CXD9646B
IC302 8-759-533-85 IC BA05FP-E2
IC303 8-759-583-47 IC uPC2933T-E2
IC304 6-701-741-01 IC CXD9646B
IC305 6-700-279-01 IC CXD9634Q
IC306 6-701-741-01 IC CXD9646B
IC307 6-701-741-01 IC CXD9646B
IC308 6-700-279-01 IC CXD9634Q
IC309 6-701-741-01 IC CXD9646B
IC310 6-700-279-01 IC CXD9634Q
IC311 6-701-741-01 IC CXD9646B
IC312 8-759-834-30 IC MC74VHC1G08DFT1
< JACK >
J401 1-694-656-21 TERMINAL BOARD (6CH SPEAKER) (SPEAKER)
< JUMPER RESISTOR >
JR400 1-216-295-91 SHORT CHIP 0
JR401 1-216-295-91 SHORT CHIP 0
JR402 1-216-295-91 SHORT CHIP 0
JR403 1-216-295-91 SHORT CHIP 0
< COIL >
L300 1-216-295-91 SHORT CHIP 0
L302 1-412-939-11 INDUCTOR 1uH
L401 1-424-777-11 INDUCTOR 10uH
L402 1-424-777-11 INDUCTOR 10uH
L403 1-424-777-11 INDUCTOR 10uH
L404 1-424-777-11 INDUCTOR 10uH
L405 1-424-777-11 INDUCTOR 10uH
L406 1-424-777-11 INDUCTOR 10uH
< TRANSISTOR >
Q301 8-729-119-78 TRANSISTOR 2SC2785-HFE
AMP
