70
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-S400
C662 1-126-964-11 ELECT 10uF 20% 50V
C671 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C672 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C700 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C701 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C707 1-117-370-11 CERAMIC CHIP 10uF 10V
C723 1-124-261-00 ELECT 10uF 20% 50V
C724 1-125-972-61 ELECT 100uF 20% 16V
C725 1-124-234-00 ELECT 22uF 20% 16V
C730 1-125-972-61 ELECT 100uF 20% 16V
C731 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C802 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C803 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
< CONNECTOR >
CN600 1-794-431-11 CONNECTOR, FFC/FPC 13P
CN601 1-779-297-11 CONNECTOR, FFC(LIF(NON-ZIF))29P
CN700 1-779-277-11 CONNECTOR, FFC(LIF(NON-ZIF))9P
< DIODE >
D601 8-719-056-85 DIODE UDZ-TE-17-8.2B
D602 8-719-056-78 DIODE UDZ-TE-17-4.3B
< IC >
IC600 8-759-385-76 IC MC14052BDR2
IC602 8-749-923-05 IC TORX178B (AUDIO 2)
IC604 8-759-557-36 IC BU1924F-E2
IC701 8-759-680-28 IC BA7666FS-E2
< JACK >
J600 1-779-688-11 JACK, PIN 6P (AUDIO 1/AUDIO 2)
J700 1-785-867-11 JACK, PIN 1P (MONITOR OUT)
< COIL >
L600 1-216-295-91 SHORT CHIP 0
L601 1-469-525-91 INDUCTOR 10uH
L700 1-412-953-11 INDUCTOR 15uH
L707 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q600 8-729-801-93 TRANSISTOR 2SD1387-3
Q601 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q602 8-729-901-00 TRANSISTOR DTC124EK
Q603 8-729-901-00 TRANSISTOR DTC124EK
Q604 8-729-901-00 TRANSISTOR DTC124EK
Q605 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
Q606 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
Q607 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R600 1-216-813-11 METAL CHIP 220 5% 1/16W
R601 1-216-813-11 METAL CHIP 220 5% 1/16W
R602 1-216-813-11 METAL CHIP 220 5% 1/16W
R603 1-216-813-11 METAL CHIP 220 5% 1/16W
R604 1-216-813-11 METAL CHIP 220 5% 1/16W
R605 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R606 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R607 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R608 1-216-864-11 METAL CHIP 0 5% 1/16W
R609 1-216-839-11 METAL CHIP 33K 5% 1/16W
R610 1-216-833-11 METAL CHIP 10K 5% 1/16W
R611 1-216-809-11 METAL CHIP 100 5% 1/16W
R612 1-216-839-11 METAL CHIP 33K 5% 1/16W
R613 1-216-833-11 METAL CHIP 10K 5% 1/16W
R614 1-216-809-11 METAL CHIP 100 5% 1/16W
R615 1-216-845-11 METAL CHIP 100K 5% 1/16W
R616 1-216-845-11 METAL CHIP 100K 5% 1/16W
R617 1-216-839-11 METAL CHIP 33K 5% 1/16W
R618 1-216-839-11 METAL CHIP 33K 5% 1/16W
R619 1-216-821-11 METAL CHIP 1K 5% 1/16W
R620 1-216-821-11 METAL CHIP 1K 5% 1/16W
R621 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R622 1-216-833-11 METAL CHIP 10K 5% 1/16W
R623 1-216-821-11 METAL CHIP 1K 5% 1/16W
R624 1-216-841-11 METAL CHIP 47K 5% 1/16W
R625 1-216-833-11 METAL CHIP 10K 5% 1/16W
R626 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R627 1-216-833-11 METAL CHIP 10K 5% 1/16W
R628 1-216-833-11 METAL CHIP 10K 5% 1/16W
R629 1-216-841-11 METAL CHIP 47K 5% 1/16W
R630 1-216-833-11 METAL CHIP 10K 5% 1/16W
R631 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R632 1-216-833-11 METAL CHIP 10K 5% 1/16W
R633 1-216-821-11 METAL CHIP 1K 5% 1/16W
R634 1-216-833-11 METAL CHIP 10K 5% 1/16W
R635 1-216-841-11 METAL CHIP 47K 5% 1/16W
R636 1-216-833-11 METAL CHIP 10K 5% 1/16W
R637 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R638 1-216-833-11 METAL CHIP 10K 5% 1/16W
R639 1-216-841-11 METAL CHIP 47K 5% 1/16W
R640 1-216-833-11 METAL CHIP 10K 5% 1/16W
R641 1-216-809-11 METAL CHIP 100 5% 1/16W
R642 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R643 1-216-853-11 METAL CHIP 470K 5% 1/16W
R644 1-216-845-11 METAL CHIP 100K 5% 1/16W
R645 1-216-821-11 METAL CHIP 1K 5% 1/16W
R646 1-216-814-11 METAL CHIP 270 5% 1/16W
R647 1-216-841-11 METAL CHIP 47K 5% 1/16W
R648 1-216-843-11 METAL CHIP 68K 5% 1/16W
R649 1-216-845-11 METAL CHIP 100K 5% 1/16W
R650 1-216-845-11 METAL CHIP 100K 5% 1/16W
R700 1-218-289-11 RES-CHIP 510 5% 1/10W
R705 1-218-285-11 RES-CHIP 75 5% 1/10W
< VIBRATOR >
X601 1-579-242-41 VIBRATOR, CRYSTAL (4.332MHz)
******************************************************
1-674-336-21 LOADING BOARD
*************
< CONNECTOR >
* CN1 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S1 1-786-203-11 SWITCH, LEVER (SLIDE) (TRAY OPEN)
******************************************************
I/O LOADING
To Next Page
