Sony HCD-SD1 - Connector Section Printed Wiring Board

HCD-SD1
– 45 –
– 46 –
7-15. PRINTED WIRING BOARD – CONNECTOR SECTION –
• See page 16 for Circuit Boards Location.
• Semiconductor
Location
11
(11)
CN291
S291
(LOAD OUT)
1
2
3
4
5
M904
(LOADING
MOTOR)
M
LOADING BOARD
S292
(LOAD IN)
1-634-461-
(Page 32)
(Page 34)
(Page 31, 32)
(Page 42)
DIGITAL
OPTICAL
CD AUX
SPEAKER
INPEDANCE
SYSTEM
CONTROL
AEP, UK
D501 B-3
D556 B-3
D557 C-3
D881 D-2
IC311 B-5
Q501 B-2
Q502 B-2
Q503 B-3
Q504 B-3
Ref. No. Location
