– 8 –
SECTION 3
DISASSEMBLY
Note: Follow the disassembly procedure in the numerical order given.
3-1. LOADING PANEL
3-2. GLASS ASSY
1 Turn ON the power, and press the EJECT button to open the
tray.
2 Remove the loading panel in the arrow direction.
3 Press the EJECT button to close the tray.
• If the power cannot be turned ON, refer to “Opening the Disc
Tray When the Power is OFF” of “Service Note”, and open the
tray.
Power button
Loading panel
Eject butto
To Next Page
