Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
35
MAIN
< CONNECTOR >
* CN306 1-568-954-11 PIN, CONNECTOR 5P
* CN315 1-568-936-11 PIN, CONNECTOR 9P
* CN316 1-569-935-11 SOCKET, CONNECTOR 19P
CN401 1-569-937-11 SOCKET, CONNECTOR 21P
CN802 1-785-951-11 CONNECTOR, FFC/FPC (ZIF) 18P
CN804 1-785-952-11 CONNECTOR, FFC/FPC (ZIF) 20P
CN806 1-794-393-11 CONNECTOR, FFC/FPC 23P
< DIODE >
D301 8-719-110-31 DIODE RD12ES-B2
D303 8-719-921-63 DIODE MTZJ-7.5B
D304 8-719-921-75 DIODE MTZN-10B
D305 8-719-109-89 DIODE RD5.6ESB2
D306 8-719-110-03 DIODE RD7.5ESB2
D307 8-719-991-33 DIODE 1SS133T-77
D308 8-719-921-40 DIODE MTZJ-4.7C (TH,EA)
D308 8-719-109-85 DIODE RD5.1ES-B2 (SP,MY,HK)
D311 8-719-991-33 DIODE 1SS133T-77
D313 8-719-991-33 DIODE 1SS133T-77
D350 8-719-110-31 DIODE RD12ES-B2
D651 8-719-200-82 DIODE 11ES2
D652 8-719-200-82 DIODE 11ES2
D801 8-719-991-33 DIODE 1SS133T-77
D802 8-719-991-33 DIODE 1SS133T-77
D812 8-719-991-33 DIODE 1SS133T-77
D813 8-719-991-33 DIODE 1SS133T-77
D814 8-719-991-33 DIODE 1SS133T-77
D815 8-719-991-33 DIODE 1SS133T-77
< IC >
IC101 8-759-584-38 IC TDA7296
IC201 8-759-584-38 IC TDA7296
IC301 8-759-585-01 IC IC TDA7439
IC303 8-759-545-66 IC NJM3414AMP(TE2)
IC304 8-759-584-41 IC K1A7808PI
IC305 8-759-584-40 IC KA7908
IC307 8-759-909-71 IC BA4558F
IC308 8-749-921-12 IC GP1F32T (CD DIGITAL OUT OPTICAL)
IC309 8-759-584-65 IC KA3082
IC310 8-759-324-40 IC KIA7805PI
IC311 8-759-584-41 IC K1A7808PI
IC312 8-759-641-63 IC KIA79L05BP-AT
IC315 8-759-909-71 IC BA4558F
IC801 8-752-905-94 IC IC CXP83120A-041Q
IC803 8-759-584-64 IC BMR0301H
< JACK >
PJ301 1-785-926-11 JACK, PIN 6P (LINE OUT/MD IN/VIDEO IN)
< TRANSISTOR >
Q101 8-729-920-31 TRANSISTOR DTC343TK
Q102 8-729-920-31 TRANSISTOR DTC343TK
Q103 8-729-920-31 TRANSISTOR DTC343TK
Q106 8-729-920-31 TRANSISTOR DTC343TK
Q111 8-729-920-31 TRANSISTOR DTC343TK
Q201 8-729-920-31 TRANSISTOR DTC343TK
Q202 8-729-920-31 TRANSISTOR DTC343TK
Q203 8-729-920-31 TRANSISTOR DTC343TK
Q206 8-729-920-31 TRANSISTOR DTC343TK
Q211 8-729-920-31 TRANSISTOR DTC343TK
Q301 8-729-019-00 TRANSISTOR 2SD2394-G
Q302 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q303 8-729-901-00 TRANSISTOR DTC124EK
Q307 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q308 8-729-900-53 TRANSISTOR DTC114EK
Q310 8-729-019-00 TRANSISTOR 2SD2394-G
Q311 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q312 8-729-901-00 TRANSISTOR DTC124EK
Q313 8-729-028-54 TRANSISTOR KTC3205
Q314 8-729-028-54 TRANSISTOR KTC3205
Q315 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q316 8-729-901-00 TRANSISTOR DTC124EK
Q317 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q318 8-729-901-00 TRANSISTOR DTC124EK
Q321 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q322 8-729-901-00 TRANSISTOR DTC124EK
Q350 8-729-019-00 TRANSISTOR 2SD2394-G
Q351 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q352 8-729-901-00 TRANSISTOR DTC124EK
Q393 8-729-900-53 TRANSISTOR DTC114EK
Q651 8-729-900-53 TRANSISTOR DTC114EK
Q652 8-729-801-84 TRANSISTOR 2SB1013-4
Q653 8-729-801-84 TRANSISTOR 2SB1013-4
Q654 8-729-900-53 TRANSISTOR DTC114EK
Q655 8-729-900-53 TRANSISTOR DTC114EK
Q656 8-729-202-56 TRANSISTOR 2SA950-Y
Q657 8-729-202-56 TRANSISTOR 2SA950-Y
Q658 8-729-900-53 TRANSISTOR DTC114EK
Q659 8-729-900-53 TRANSISTOR DTC114EK
Q661 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q662 8-729-900-53 TRANSISTOR DTC114EK
Q829 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q830 8-729-920-31 TRANSISTOR DTC343TK
< RESISTOR >
R102 1-216-295-91 SHORT 0
R103 1-216-049-91 RES-CHIP 1K 5% 1/10W
R105 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R106 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R107 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R108 1-216-072-00 METAL CHIP 9.1K 5% 1/10W
R109 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R110 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R111 1-216-049-91 RES-CHIP 1K 5% 1/10W
R112 1-216-043-91 RES-CHIP 560 5% 1/10W
R113 1-216-089-91 RES-CHIP 47K 5% 1/10W
R114 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R115 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R116 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R117 1-216-089-91 RES-CHIP 47K 5% 1/10W
R118 1-216-089-91 RES-CHIP 47K 5% 1/10W
R119 1-216-043-91 RES-CHIP 560 5% 1/10W
R120 1-216-085-00 METAL CHIP 33K 5% 1/10W
R121 1-216-049-91 RES-CHIP 1K 5% 1/10W
R122 1-216-025-91 RES-CHIP 100 5% 1/10W
