Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
38
HCD-VP11
9-929-290-11
Sony Corporation
Audio Entertainment Group
2000G16075-1D
Printed in Japan ©2000.7
Published by HA Quality Assurance Dept.
POWER
< FUSE >
0F901 1-533-464-11 FUSE, GLASS TUBE (DIA. 5) 0.8A/250V
0F902 1-533-468-11 FUSE, GLASS TUBE (DIA. 5) 2A/250V
0F903 1-533-468-11 FUSE, GLASS TUBE (DIA. 5) 2A/250V
< SWITCH >
0S901 1-552-921-00 SWITCH, POWER (VOLTAGE SELECTOR)
< TRANSFORMER >
0T901 1-435-604-11 TRANSFORMER, POWER
************************************************************
1-677-146-21 SPEAKER BOARD
**************
< CAPACITOR >
C127 1-130-495-00 MYLAR 0.1uF 5% 50V
C133 1-130-495-00 MYLAR 0.1uF 5% 50V
C227 1-130-495-00 MYLAR 0.1uF 5% 50V
C233 1-130-495-00 MYLAR 0.1uF 5% 50V
< CONNECTOR >
* CN301 1-573-455-11 PLUG, CONNECTOR (2.5MM) 4P
< COIL >
L101 1-420-872-00 COIL, AIR-CORE
L201 1-420-872-00 COIL, AIR-CORE
< RESISTOR >
R127 1-216-150-91 RES-CHIP 10 5% 1/8W
R141 1-216-150-91 RES-CHIP 10 5% 1/8W
R227 1-216-150-91 RES-CHIP 10 5% 1/8W
R241 1-216-150-91 RES-CHIP 10 5% 1/8W
< JACK >
* SJ301 1-536-708-41 TERMINAL BOARD, PUSH 4P (SPEAKER)
************************************************************
1-677-362-11 VIDEO OUT BOARD
***************
1-677-302-11 LCD FPC(13.3INCH TFT XGA)
< JACK >
J401 1-793-571-11 JACK, PIN (VIDEO OUT)
< SWITCH >
SW401 1-771-788-11 SWITCH, SLIDE (NTSC/AUTO/PAL)
************************************************************
MISCELLANEOUS
**************
1 1-772-623-11 DECK, MECHANICAL (TAPE DECK BLOCK)
60 1-792-413-11 CABLE, FLEXIBLE FLAT (18 CORE)
61 1-792-412-11 CABLE, FLEXIBLE FLAT (20 CORE)
0112 1-556-091-00 CORD, POWER (TH)
0112 1-696-169-11 CORD, POWER (SP,MY,EA,HK)
0113 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
114 1-792-409-11 CABLE, FLEXIBLE FLAT (21 CORE)
115 1-792-415-11 CABLE, FLEXIBLE FLAT (19 CORE)
116 1-792-412-11 CABLE, FLEXIBLE FLAT (20 CORE)
117 1-792-413-11 CABLE, FLEXIBLE FLAT (18 CORE)
118 1-792-410-11 CABLE, FLEXIBLE FLAT (23 CORE)
120 1-761-268-11 BOARD, MPEG
0202 8-848-483-05 OPTICAL PICK-UP KSM-213CKP/K1N
M901 A-4672-891-A MOTOR (LOADING) ASSY
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-546-14 SCREW +BTP 3X8 TYPE2 N-S
#2 7-685-245-19 SCREW +KTP 3X6 TYPE2 NON-SLIT
#3 7-685-246-14 SCREW +KTP 3X8 TYPE2 NON-SLIT
#4 7-685-659-14 SCREW +BVTP 4X8 TYPE2 N-S
#9 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
