Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
101 4-965-822-01 FOOT
* 102 1-672-369-11 TRANSFORMER BOARD
* 103 3-703-244-00 BUSHING (2104), CORD (VX5A: EA, MY, SP,
HK, TW/VX5AJ: EA/VX7A: EA, MY, SP)
103 3-703-571-11 BUSHING (S) (4516), CORD
(VX5A: E, TH/VX5AJ: E, JE/VX7A: E, TH)
103 4-966-266-01 BUSHING (S) (FBS002), CORD
(VX5A: IA/VX7A: IA)
104 1-773-043-11 WIRE (FLAT TYPE) (17 CORE)
105 1-773-024-11 WIRE (FLAT TYPE) (15 CORE) (32cm)
106 1-783-949-11 WIRE (FLAT TYPE) (13 CORE) (17cm)
107 A-4419-156-A MAIN BOARD, COMPLETE
(VX5A: E, MY, SP, HK, TW)
107 A-4419-164-A MAIN BOARD, COMPLETE (VX7A: E, MY, SP)
107 A-4419-661-A MAIN BOARD, COMPLETE (VX5A: EA)
107 A-4419-663-A MAIN BOARD, COMPLETE (VX7A: EA)
107 A-4426-090-A MAIN BOARD, COMPLETE (VX5AJ: E)
107 A-4426-098-A MAIN BOARD, COMPLETE (VX5AJ: JE)
107 A-4426-100-A MAIN BOARD, COMPLETE (VX5AJ: EA)
107 A-4426-135-A MAIN BOARD, COMPLETE (VX5A: IA)
107 A-4426-143-A MAIN BOARD, COMPLETE (VX7A: IA)
107 A-4426-160-A MAIN BOARD, COMPLETE (VX5A: TH)
107 A-4426-167-A MAIN BOARD, COMPLETE (VX7A: TH)
108 4-215-639-01 PANEL, BACK (VX5A: EA)
108 4-215-639-11 PANEL, BACK (VX5A: MY, SP)
108 4-215-639-21 PANEL, BACK (VX5A: TW)
108 4-215-639-31 PANEL, BACK (VX5A: E)
108 4-215-639-41 PANEL, BACK (VX5A: TH)
108 4-215-639-51 PANEL, BACK (VX5A: HK)
108 4-215-639-61 PANEL, BACK (VX5A: IA)
108 4-215-639-71 PANEL, BACK (VX5AJ: EA)
108 4-215-639-81 PANEL, BACK (VX5AJ: JE)
108 4-215-639-91 PANEL, BACK (VX5AJ: E)
108 4-215-640-01 PANEL, BACK (VX7A: EA)
108 4-215-640-11 PANEL, BACK (VX7A: MY, SP)
108 4-215-640-41 PANEL, BACK (VX7A: E, IA, TH)
109 1-769-977-11 WIRE (FLAT TYPE) (13 CORE) (15cm)
(VX5A: TH/VX7A: TH)
109 1-773-009-11 WIRE (FLAT TYPE) (15 CORE) (15cm)
(VX5A: E, EA, MY, SP, IA, HK, TW/VX5AJ/
VX7A: E, EA, MY, SP, IA)
110 1-233-545-11 TUNER (FM/AM) (VX5A: TH/VX7A: TH)
110 1-233-546-11 TUNER (FM/MW/SW)
(VX5A: E, EA, MY, SP, IA, HK, TW/VX5AJ: E, EA/
VX7A: E, EA, MY, SP, IA)
110 1-693-465-11 TUNER (PACK) (VX5AJ: JE)
! 111 1-575-651-11 CORD, POWER (VX5A: EA, MY, SP, HK, TW/
VX5AJ: EA/VX7A: EA, MY, SP)
! 111 1-575-653-11 CORD, POWER (VX5A: E, IA, TH/VX5AJ: E, JE/
VX7A: E, IA, TH)
! 112 1-569-007-11 ADAPTOR, CONVERSION 2P (VX5A: E, IA/
VX5AJ: E, JE/VX7A: E, IA)
! 112 1-569-008-21 ADAPTOR, CONVERSION 2P (VX5A: EA, MY,
SP, TW/VX5AJ: EA/VX7A: EA, MY, SP)
! 112 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (VX5A: HK)
113 A-4426-097-A SURROUND BOARD, COMPLETE
114 A-4724-823-A VIDEO BOARD, COMPLETE
115 1-775-212-11 WIRE (FLAT TYPE) (23 CORE) (18cm)
M501 1-698-792-11 FAN, DC
! T951 1-433-561-21 TRANSFORMER, POWER (VX7A)
! T951 1-433-565-11 TRANSFORMER, POWER (VX5A)
! T951 1-433-565-21 TRANSFORMER, POWER (VX5AJ)
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
