Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R157 1-216-025-00 RES, CHIP 100 5% 1/10W
R158 1-216-111-00 METAL CHIP 390K 5% 1/10W
R159 1-216-089-00 RES, CHIP 47K 5% 1/10W
R161 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
R171 1-216-025-00 RES, CHIP 100 5% 1/10W
R172 1-216-025-00 RES, CHIP 100 5% 1/10W
R173 1-216-025-00 RES, CHIP 100 5% 1/10W
R175 1-216-025-00 RES, CHIP 100 5% 1/10W
R203 1-216-025-00 RES, CHIP 100 5% 1/10W
R204 1-216-025-00 RES, CHIP 100 5% 1/10W
R205 1-216-025-00 RES, CHIP 100 5% 1/10W
R206 1-216-295-00 SHORT 0
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
**************************************************************
A-4419-984-A CD SW BOARD, COMPLETE
**********************
< LED >
D751 8-719-056-13 LED SML79423C-TP15 (DISC 1)
D752 8-719-056-13 LED SML79423C-TP15 (DISC 2)
D753 8-719-056-13 LED SML79423C-TP15 (DISC 3)
D754 8-719-063-93 LED SLR325VC-N-T32 (1/u)
< RESISTOR >
R751 1-249-417-11 CARBON 1K 5% 1/4W
R752 1-249-418-11 CARBON 1.2K 5% 1/4W
R753 1-249-420-11 CARBON 1.8K 5% 1/4W
R754 1-249-422-11 CARBON 2.7K 5% 1/4W
R755 1-247-843-11 CARBON 3.3K 5% 1/4W
R756 1-249-425-11 CARBON 4.7K 5% 1/4W
R757 1-249-427-11 CARBON 6.8K 5% 1/4W
R758 1-247-804-11 CARBON 75 5% 1/4W
R759 1-249-407-11 CARBON 150 5% 1/4W
R760 1-247-804-11 CARBON 75 5% 1/4W
R761 1-249-407-11 CARBON 150 5% 1/4W
R762 1-247-804-11 CARBON 75 5% 1/4W
R763 1-249-407-11 CARBON 150 5% 1/4W
R764 1-249-414-11 CARBON 560 5% 1/4W
< SWITCH >
S751 1-762-875-21 SWITCH, KEYBOARD (1/u)
S752 1-762-875-21 SWITCH, KEYBOARD
( (STANDBY) POWER SAVE DEMO)
S753 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S754 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S755 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S756 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP EX-CHANGE)
S757 1-762-875-21 SWITCH, KEYBOARD (§)
**************************************************************
* 1-658-575-11 CONNECTOR BOARD
*****************
< CONNECTOR >
* CN701 1-568-946-11 PIN, CONNECTOR 8P
CN702 1-785-550-11 CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR BA1A4M-TP
< RESISTOR >
R703 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W
**************************************************************
* A-2007-732-A LEAF SW BOARD, COMPLETE
************************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-568-860-11 SOCKET, CONNECTOR 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS119
D1002 8-719-911-19 DIODE 1SS119
< CONNECTOR >
* DM1001 1-784-581-11 HOLDER, CABLE (2.5MM PITCH) 4P
< PHOTO INTERRUPTER >
IC1001 8-749-014-38 PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA
< RESISTOR >
R907 1-247-879-11 CARBON 100K 5% 1/4W
R1001 1-249-409-11 CARBON 220 5% 1/4W
R1002 1-249-409-11 CARBON 220 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-856-00 CARBON 11K 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY) (DECK A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY) (DECK B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (DECK A HALF)
S1004 1-771-205-11 SWITCH, LEAF (DECK A 120/70)
S1005 1-771-205-11 SWITCH, LEAF (DECK A REC)
S1006 1-771-333-11 SWITCH, LEAF (DECK B HALF)
BD CD SW CONNECTOR LEAF SW
