– 114 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R559 1-216-073-00 METAL CHIP 10K 5% 1/10W
R560 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R561 1-216-049-11 RES, CHIP 1K 5% 1/10W
R562 1-216-025-00 RES, CHIP 100 5% 1/10W
R563 1-216-025-00 RES, CHIP 100 5% 1/10W
R564 1-216-025-00 RES, CHIP 100 5% 1/10W
R565 1-216-025-00 RES, CHIP 100 5% 1/10W
R566 1-216-025-00 RES, CHIP 100 5% 1/10W
R567 1-216-073-00 METAL CHIP 10K 5% 1/10W
R568 1-216-073-00 METAL CHIP 10K 5% 1/10W
R569 1-216-073-00 METAL CHIP 10K 5% 1/10W
R572 1-216-073-00 METAL CHIP 10K 5% 1/10W
R573 1-216-073-00 METAL CHIP 10K 5% 1/10W
R574 1-216-073-00 METAL CHIP 10K 5% 1/10W
R577 1-216-081-00 METAL CHIP 22K 5% 1/10W
R578 1-216-081-00 METAL CHIP 22K 5% 1/10W
R579 1-216-073-00 METAL CHIP 10K 5% 1/10W
R580 1-216-073-00 METAL CHIP 10K 5% 1/10W
< SWITCH >
S501 1-571-395-11 SWITCH, SLIDE (SYSTEM SELECT)
< VIBRATOR >
X501 1-767-510-41 VIBRATOR, CERAMIC (10MHz)
X503 1-767-519-11 VIBRATOR, CRYSTAL (27MHz)
************************************************************
MISCELLANEOUS
**************
64 1-773-188-11 WIRE (FLAT TYPE) (23 CORE) (23cm)
104 1-773-043-11 WIRE (FLAT TYPE) (17 CORE)
105 1-773-024-11 WIRE (FLAT TYPE) (15 CORE) (32cm)
106 1-783-949-11 WIRE (FLAT TYPE) (13 CORE) (17cm)
109 1-769-977-11 WIRE (FLAT TYPE) (13 CORE) (15cm)
(VX5A: TH/VX7A: TH)
109 1-773-009-11 WIRE (FLAT TYPE) (15 CORE) (15cm)
(VX5A: E, EA, MY, SP, IA, HK, TW/VX5AJ/
VX7A: E, EA, MY, SP, IA)
110 1-233-545-11 TUNER (FM/AM) (VX5A: TH/VX7A: TH)
110 1-233-546-11 TUNER (FM/MW/SW)
(VX5A: E, EA, MY, SP, IA, HK, TW/VX5AJ: E, EA/
VX7A: E, EA, MY, SP, IA)
110 1-693-465-11 TUNER (PACK) (VX5AJ: JE)
! 111 1-575-651-11 CORD, POWER (VX5A: EA, MY, SP, HK, TW/
VX5AJ: EA/VX7A: EA, MY, SP)
! 111 1-575-653-11 CORD, POWER (VX5A: E, IA, TH/VX5AJ: E, JE/
VX7A: E, IA, TH)
! 112 1-569-007-11 ADAPTOR, CONVERSION 2P (VX5A: E, IA/
VX5AJ: E, JE/VX7A: E, IA)
! 112 1-569-008-21 ADAPTOR, CONVERSION 2P (VX5A: EA, MY,
SP, TW/VX5AJ: EA/VX7A: EA, MY, SP)
! 112 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (VX5A: HK)
115 1-775-212-11 WIRE (FLAT TYPE) (23 CORE) (18cm)
257 1-452-925-21 MAGNET ASSY
258 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
! 301 8-820-020-02 OPTICAL PICK-UP KSS-213D/Q-NP
302 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
HP101 A-2056-681-A DECK (A) ASSY, HEAD
HRPE101A-2056-682-A DECK (B) ASSY, HEAD
M1 A-2004-628-A MOTOR ASSY, CAPSTAN
M101 X-4917-523-4 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M501 1-698-792-11 FAN, DC
M701 A-4672-004-A MOTOR ASSY (DISC TRAY TURN)
M801 A-4672-004-A MOTOR ASSY (DISC TRAY SLIDE)
S811 1-473-335-11 ENCODER, ROTARY (BU, TRAY ADDRESS DET)
! T951 1-433-561-21 TRANSFORMER, POWER (VX7A)
! T951 1-433-565-11 TRANSFORMER, POWER (VX5A)
! T951 1-433-565-21 TRANSFORMER, POWER (VX5AJ)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-872-09 SCREW +BVTT 3X8 (S)
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-871-01 SCREW +BVTT 3X6 (S)
#4 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#5 7-685-852-04 SCREW +BVTT 2X5 (S)
#6 7-685-861-01 SCREW +BVTT 2.6X5 (S)
#7 7-685-851-04 SCREW +BVTT 2X4 (S)
#8 7-621-775-10 SCREW +B 2.6X4
#9 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#10 7-685-872-09 SCREW +BVTT 3X8 (S) (VX5A: HK, TW/VX5AJ)
#10 7-685-880-09 SCREW +BVTT 4X6 (S)
(VX5A: E, EA, MY, SP, IA, TH/VX7A)
#11 7-628-254-15 SCREW +PS 2.6X6
#12 7-628-254-50 SCREW +PS 2.6X16
VIDEO
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
Sony Corporation
Home Audio Company9-928-874-11
99E057025-1
Printed in Singapore © 1999. 5
Published by Quality Assurance Dept.
