70
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR66/XGR600
C891 1-127-751-11 ELECT 3300uF 20% 50V
(XGR600)
C892 1-127-815-11 ELECT 3300uF 20% 100V
(XGR66)
C892 1-127-814-11 ELECT 3300uF 20% 80V
(XGR600)
C894 1-137-749-11 MYLAR 0.1uF 100V
C895 1-107-721-11 ELECT 4.7uF 20% 100V
C902 1-164-159-11 CERAMIC 0.1uF 50V
C903 1-126-933-11 ELECT 100uF 20% 16V
C904 1-126-964-11 ELECT 10uF 20% 50V
C905 1-126-968-11 ELECT 100uF 20% 50V
C906 1-126-943-11 ELECT 2200uF 20% 25V
C909 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN803 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN804 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
* CN806 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN904 1-785-316-11 PIN, CONNECTOR (STRAIGHT) 4P
< DIODE >
D401 8-719-991-33 DIODE 1SS133T-72
D402 8-719-991-33 DIODE 1SS133T-72
D405 8-719-991-33 DIODE 1SS133T-72
D406 8-719-991-33 DIODE 1SS133T-72
D801 8-719-991-33 DIODE 1SS133T-72
D802 8-719-110-48 DIODE MTZJ-T-72-18A (XGR66)
D802 8-719-947-60 DIODE MTZJ-T-72-15A (XGR600)
D803 8-719-991-33 DIODE 1SS133T-72
D804 8-719-991-33 DIODE 1SS133T-72
D805 8-719-991-33 DIODE 1SS133T-72
D831 8-719-510-68 DIODE D5SBA204101
D833 6-500-522-11 DIODE 10EDB40-TA2B5
D834 6-500-522-11 DIODE 10EDB40-TA2B5
D835 6-500-522-11 DIODE 10EDB40-TA2B5
D836 6-500-522-11 DIODE 10EDB40-TA2B5
D841 6-500-522-11 DIODE 10EDB40-TA2B5
D842 6-500-522-11 DIODE 10EDB40-TA2B5
D843 6-500-522-11 DIODE 10EDB40-TA2B5
D844 6-500-522-11 DIODE 10EDB40-TA2B5
D851 8-719-991-33 DIODE 1SS133T-72
D852 8-719-110-48 DIODE MTZJ-T-72-18A (XGR66)
D852 8-719-947-60 DIODE MTZJ-T-72-15A (XGR600)
D853 8-719-991-33 DIODE 1SS133T-72
D902 6-500-522-11 DIODE 10EDB40-TA2B5
D903 6-500-522-11 DIODE 10EDB40-TA2B5
D904 6-500-522-11 DIODE 10EDB40-TA2B5
D905 6-500-522-11 DIODE 10EDB40-TA2B5
D911 8-719-983-86 DIODE MTZJ-T-72-33A
D912 8-719-109-89 DIODE MTZJ-T-72-5.6
< IC >
IC801 8-749-017-06 IC STK412-150 (XGR66)
IC801 6-600-169-01 IC STK412-240 (XGR600)
IC901 6-701-760-01 IC uPC3504AHF
< COILE >
L401 1-422-009-13 COIL, AIR-CORE
L402 1-422-009-13 COIL, AIR-CORE
< TRANSISTOR >
Q401 8-729-029-40 TRANSISTOR DTA124ESA-TP (XGR66)
Q401 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA (XGR600)
Q402 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q431 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q801 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q803 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q804 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q805 8-729-231-55 TRANSISTOR 2SC2878AB-TPE2
Q831 8-729-029-86 TRANSISTOR DTC124ESA-TP
Q832 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q833 8-729-029-40 TRANSISTOR DTA124ESA-TP
Q834 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q842 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q843 8-729-029-86 TRANSISTOR DTC124ESA-TP
Q851 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q855 8-729-231-55 TRANSISTOR 2SC2878AB-TPE2
Q901 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q903 8-729-048-52 TRANSISTOR 2SA1932(TP)
Q908 8-729-119-76 TRANSISTOR 2SA1115TP-EF
< RESISTOR >
0 R401 1-216-431-11 METAL OXIDE 560 5% 1W
(XGR66)
0 R401 1-216-458-11 METAL OXIDE 1.8K 5% 2W
(XGR600)
R406 1-249-437-11 CARBON 47K 5% 1/4W
R407 1-249-437-11 CARBON 47K 5% 1/4W
R410 1-249-389-11 CARBON 4.7 5% 1/4W F
R411 1-249-389-11 CARBON 4.7 5% 1/4W F
R412 1-249-389-11 CARBON 4.7 5% 1/4W F
R413 1-249-389-11 CARBON 4.7 5% 1/4W F
R414 1-260-076-11 CARBON 10 5% 1/2W
R415 1-260-076-11 CARBON 10 5% 1/2W
R429 1-249-437-11 CARBON 47K 5% 1/4W
R431 1-249-438-11 CARBON 56K 5% 1/4W
R432 1-249-437-11 CARBON 47K 5% 1/4W
R439 1-249-425-11 CARBON 4.7K 5% 1/4W F
R446 1-249-429-11 CARBON 10K 5% 1/4W
R447 1-249-437-11 CARBON 47K 5% 1/4W
R460 1-249-429-11 CARBON 10K 5% 1/4W
(XGR600)
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-413-11 CARBON 470 5% 1/4W F
R804 1-249-435-11 CARBON 33K 5% 1/4W
R805 1-216-436-00 METAL OXIDE 3.9K 5% 1W
R806 1-216-436-00 METAL OXIDE 3.9K 5% 1W
0 R807 1-212-881-11 FUSIBLE 100 5% 1/4W
0 R808 1-219-718-11 METAL 0.1 10% 5W
(XGR66)
0 R808 1-220-893-11 METAL 0.22 10% 5W
(XGR600)
R809 1-260-076-11 CARBON 10 5% 1/2W
R810 1-249-437-11 CARBON 47K 5% 1/4W
R811 1-249-417-11 CARBON 1K 5% 1/4W F
R812 1-249-431-11 CARBON 15K 5% 1/4W
R813 1-249-441-11 CARBON 100K 5% 1/4W
R814 1-249-421-11 CARBON 2.2K 5% 1/4W F
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
PA
