73
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR66/XGR600
SUB TRANS TC-A TRANS
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
SENSORPANEL VR
< COIL >
L701 1-410-509-11 INDUCTOR 10uH
< RESISTOR >
R701 1-249-429-11 CARBON 10K 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R703 1-247-807-31 CARBON 100 5% 1/4W
R704 1-247-807-31 CARBON 100 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W F
R706 1-249-417-11 CARBON 1K 5% 1/4W F
R707 1-249-415-11 CARBON 680 5% 1/4W F
R708 1-249-402-11 CARBON 56 5% 1/4W F
R709 1-249-402-11 CARBON 56 5% 1/4W F
R710 1-249-402-11 CARBON 56 5% 1/4W F
R711 1-249-403-11 CARBON 68 5% 1/4W F
R712 1-249-403-11 CARBON 68 5% 1/4W F
R713 1-249-403-11 CARBON 68 5% 1/4W F
R714 1-249-403-11 CARBON 68 5% 1/4W F
R715 1-249-403-11 CARBON 68 5% 1/4W F
R716 1-249-403-11 CARBON 68 5% 1/4W F
R717 1-249-403-11 CARBON 68 5% 1/4W F
R718 1-249-403-11 CARBON 68 5% 1/4W F
R719 1-249-402-11 CARBON 56 5% 1/4W F
R720 1-249-402-11 CARBON 56 5% 1/4W F
R721 1-249-402-11 CARBON 56 5% 1/4W F
< VARIABLE RESISTOR >
RV801 1-225-739-11 RES, VAR CARBON 50K (MIC LEVEL)
< SWITCH >
S700 1-473-392-11 ENCODER, ROTARY (VOLUME)
S701 1-762-875-21 SWITCH, KEYBOARD (X-GROOVE)
******************************************************
*
1-659-058-13 SENSOR BOARD
************
< IC >
IC202 8-749-924-18 PHOTO INTERRUPTER RPI-1391
< RESISTOR >
R207 1-249-416-11 CARBON 820 5% 1/4W F
******************************************************
1-687-271-11 SUB TRANS BOARD
**************
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR(3.96MM PITCH)2P
CN902 1-568-106-11 PIN, CONNECTOR(3.96MM PITCH)4P (XGR66)
* CN902 1-564-321-21 PIN, CONNECTOR(3.96MM PITCH)2P (XGR600)
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-72
< RELAY >
0 RY901 1-755-467-11 RELAY (POWER)
< SWITCH >
0 S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(XGR66)
< TRANSFORMER >
0 T901 1-437-674-11 TRANSFORMER, POWER (XGR66)
0 T901 1-437-675-11 TRANSFORMER, POWER (XGR600)
******************************************************
1-687-256-11 TC-A BOARD
**********
< DIODE >
D502 8-719-058-03 DIODE SEL5423E-TP15 (g)
D503 8-719-058-03 DIODE SEL5423E-TP15 (G)
< RESISTOR >
R503 1-247-807-31 CARBON 100 5% 1/4W
R504 1-249-397-11 CARBON 22 5% 1/4W F
R505 1-249-415-11 CARBON 680 5% 1/4W F
R506 1-249-417-11 CARBON 1K 5% 1/4W F
R507 1-249-419-11 CARBON 1.5K 5% 1/4W F
R508 1-249-419-11 CARBON 1.5K 5% 1/4W F
R509 1-249-419-11 CARBON 1.5K 5% 1/4W F
R510 1-249-419-11 CARBON 1.5K 5% 1/4W F
< SWITCH >
S503 1-762-875-21 SWITCH, KEYBOARD (g)
S504 1-762-875-21 SWITCH, KEYBOARD (G)
S505 1-762-875-21 SWITCH, KEYBOARD (x)
S506 1-762-875-21 SWITCH, KEYBOARD (.m)
S507 1-762-875-21 SWITCH, KEYBOARD (M>)
S508 1-762-875-21 SWITCH, KEYBOARD (DIRECTION)
******************************************************
1-687-270-11 TRANS BOARD
***********
1-533-217-31 HOLDER, FUSE
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C834 1-137-749-11 MYLAR 0.1uF 100V
C893 1-137-749-11 MYLAR 0.1uF 100V
C961 1-162-306-11 CERAMIC 0.01uF 30% 16V
C963 1-162-306-11 CERAMIC 0.01uF 30% 16V
* CN951 1-564-214-11 PIN, CONNECTOR(3.96MM PITCH)3P
* CN952 1-564-526-11 PLUG, CONNECTOR 11P
< DIODE >
D832 8-719-510-68 DIODE D5SBA204101
< RESISTOR .
0R951 1-219-122-11 FUSEBLE 0.33
0R952 1-219-122-11 FUSEBLE 0.33
0R953 1-219-591-11 FUSEBLE 0.1 1/2W
0 R961 1-219-237-11 SOLID 3.3M 20% 1/2W
(XGR600)
******************************************************
