7
HCD-XGR90AV
SECTION 3
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
3-1. CASE
• The equipment can be removed using the following procedure.
3
Five screws (BVTT 3
×
6)
4
Two screws (BVTP 3
×
8
2
Three screws (CASE3 TP2)
1
Three screws
(CASE3 TP2)
8
Case
6
7
5
5
6
Set Case Front panel section Tape mechanism deck
PANEL FL board, TC-A board, TC-B board
PANEL VR board
MIC/GUITAR board, HEADPHONE board
FRONT INPUT board
D-SW board, CD-L board, Lid (CD) assy, CD-R board
Back panel, DC fan, MAIN board, PROLOGIC board
CD mechanism deck (CDM37B-30BD60C)
Base unit-1 (BU-30BD60C)
Disc table
Base unit-2 (BU-30BD60C) BD board
