42
<BOX CURSOR FILE>
11
1: Selects BOX CURSOR FILE and enters a BOX
CURSOR FILE name.
Sets the cursor to the left of the number when you
select BOX CURSOR FILE.
Sets the cursor to the right of the number when you
enter a BOX CURSOR FILE name.
See “To specify a character string” on page 28.
2:
3:
4:
5:
STORE Stores a BOX CURSOR FILE name in the camera.
READ (USB t CAM) Transfers BOX CURSOR FILE from a USB drive to
the camera.
WRITE (CAM t USB) Transfers BOX CURSOR FILE from the camera to a
USB drive.
<SPIRIT LEVEL>
12
INDICATOR ON, OFF
When this is set to ON, BOX MEMORY for
CURSOR does not function.
MODE 1
, 2 Switches the display method of the indicator.
REVERSE OFF
, ON Inverts the movement of the indicator horizontally.
SCALE 50% to 150%, 100%
Adjusts the horizontal width of the indicator.
H POSITION 0 to 99, 50
V POSITION 0 to 99, 97
ANGLE Sets the inclination angle. (Display only)
OFFSET –90 to +90, 0
SET
ZERO
ANGLE
Execute via ENTER. Designates the current angle as level (0°).
CLEAR Execute via ENTER. Sets OFFSET to 0.
<VF OUT>
13 (U01)
VF OUT COLOR
, Y, R, G, B, (COLOR), (Y),
(R), (G), (B), (RET), (R+G), (R+B),
(G+B)
Settings in ( ): When HDLA is attached (cannot be
changed)
RET MIX VF ON, OFF
, (ON), (OFF) Settings in ( ): When HDLA is attached (cannot be
changed)
MIX DIRECTION MAIN, RET
MIX VF MODE Y-MIX, Y/C-MIX, WIRE(W),
WIRE(B)
MIX VF LEVEL 0 to 99%
CHARACTER LEVEL 1 to 5, 4
OPERATION
Page title
PageNo.
Item Settings Description
