Sony HDC1700 - OPERATION Menu Item Settings (Assignments)

43
<SWITCH ASSIGN1>
14 (U09)
GAIN L: –6, –3, 0
, 3, 6, 9, 12 dB
M: –6, –3, 0, 3, 6
, 9, 12 dB
H: –6, –3, 0, 3, 6, 9, 12
dB
ASSIGNABLE OFF
, RETURN1 SW, RETURN2
SW, INCOM1, INCOM2, VF
DETAIL, MIX VF, 5600K, FAN
MAX, D.EXTENDER, VF ASSIGN
SW1, VF ASSIGN SW2, SPIRIT
LEVEL INDICATOR, FOCUS
ASSIST INDICATOR,
RET1 SW
TOGGLE, RET2 SW TOGGLE,
RET3 SW TOGGLE, CURSOR ALL
OFF, FLAG
JN/SY models only.
When HDLA is attached: OFF, EXTENDER, 5600K,
FAN MAX, D.EXTENDER, FLAG
Note
When you turn D.EXTENDER ON or OFF, noise
may be generated. This is not a malfunction.
OFF
, RETURN1 SW, RETURN2
SW, ENG, PROD, VF DETAIL,
MIX VF, 5600K, FAN MAX,
D.EXTENDER, VF ASSIGN SW1,
VF ASSIGN SW2, SPIRIT LEVEL
INDICATOR, FOCUS ASSIST
INDICATOR,
RET1 SW TOGGLE,
RET2 SW TOGGLE, RET3 SW
TOGGLE, CURSOR ALL OFF, FLAG
CE/E models only.
When HDLA is attached: OFF, EXTENDER, 5600K,
FAN MAX, D.EXTENDER, FLAG
Note
When you turn D.EXTENDER ON or OFF, noise
may be generated. This is not a malfunction.
VF ASSIGN OFF, VF ASSIGN SW1
, VF
ASSIGN SW2
Displayed only when HDLA is attached.
VF OUT SW VF OUT RGB
, FOCUS POSITION
METER
Displayed only when HDLA is attached. (When
FOCUS POSITION METER is set, VF OUT SW (R/G/
B) can be used for registering/displaying Marker 1/2/3.)
OPERATION
Page title
PageNo.
Item Settings Description
