38
Setup Menu
SYSTEM OPERATION
Page name
Page No.
Item Settings Description
<SD ASPECT>
S05
SD ASPECT SQUEEZE, EDGE CROP
, LETTER
BOX
Selects the SD output aspect.
SD LB SEL 16:9
, 15:9, 14:9, 13:9 Selects the LETTER BOX aspect ratio.
H-POSITION –99 to 99, (–99) to (99) 0
Sets the horizontal position.
Settings in ( ): Displayed when SQUEEZE or
LETTER BOX is selected in SD ASPECT. (Display
only)
CENTER ON
, OFF, (ON), (OFF) Sets the horizontal centering position.
Settings in ( ): Displayed when SQUEEZE or
LETTER BOX is selected in SD ASPECT. (Display
only)
V-POSITION –99 to 99, (–99) to (99) 0
Sets the vertical position.
Settings in ( ): Displayed when SQUEEZE or EDGE
CROP is selected in SD ASPECT. (Display only)
CENTER ON, OFF, (ON)
, (OFF) Sets the vertical centering position.
Settings in ( ): Displayed when SQUEEZE or EDGE
CROP is selected in SD ASPECT. (Display only)
H-INTERP A
, B, C, D, E Selects the down converter horizontal filter.
V-INTERP A
, B, C, D, E Selects the down converter vertical filter.
<RETURN FORMAT>
S06
RET1 When 1.001 is selected for
FREQUENCY HD: 1080/59.94P,
1080/59.94I (PsF)
, 1080/23.97PsF,
720/59.94P, 525/59.94I (PsF),
NTSC
When 1.000 is selected for
FREQUENCY HD: 1080/50P,
1080/50I (PsF)
, 1080/24PsF, 720/
50P, 625/50I (PsF), PAL
When 525/59.94I (PsF), NTSC,
625/50I (PsF) or PAL are selected,
the following settings are available:
SQUEEZE
, EDGE CROP, LETTER
BOX,
16:9
, 15:9, 14:9, 13:9
Sets the return signal input format.
Sets input format, aspect ratio, and letterbox mode.
The following page shows selectable RETURN
FORMAT settings at various OUTPUT FORMAT
settings.
RET4 for HDCU2500 is locked to NTSC or PAL.
RET2
RET3
RET4
AUTO SCAN Execute via EXEC. Automatically detects the return signal input format,
and then executes.
If the automatically detected result is invalid, the
previous setting flashes for 5 seconds, and then the
previous setting is maintained.
LINK TO MAIN MANUAL
/AUTO Sets the mode for linking the return signal to this
signal.
Note
Note
To Next Page
