Appendix
Appendix
Notes on Use
Use and storage locations
Avoid using or storing the unit in the following places:
• Where it is subject to extremes of temperature (operating
temperature: +5 to +40°C (41 to 104°F) for HDCU2000, –10
to +40°C (14 to 104°F) for HDCU2500). Note that in summer
the temperature in a car with the windows closed can reach
50 ° C (122 ° F).
• Very damp or dusty places.
• Where rain is likely to reach the unit.
• Places subject to severe vibration.
• Near strong magnetic fields.
• Near transmitting stations generating strong radio waves.
Avoid violent impacts
Dropping the unit, or otherwise imparting a violent shock to it,
is likely to cause it to malfunction.
Do not cover with cloth
While the unit is in operation, do not cover it with a cloth or
other material. This can cause the temperature to rise, leading
to a malfunction.
After use
Set the POWER switch on this unit to the OFF position.
Care
If the body or panels of the unit become dirty, wipe them with
a dry cloth. For severe dirt, use a soft cloth steeped in a small
amount of neutral detergent, then wipe dry. Do not use volatile
solvents such as alcohol or thinners, as these may damage
the finish.
Error Messages
When an error is detected in this unit or the camera, the
ALARM indicator turns on and an error message is displayed
on this unit.
Error message Indication
CCU:GEN LOCK NG External reference sync error
CCU:DRX NG Front DRX board power supply,
PLD error
CCU:SDI NG Rear SDI board power supply
error
CCU:PS FAN NG Power supply block fan error
CCU:PS CABLE SHORT CAMERA connector optical fiber
cable short circuit error
CCU:PS CABLE OPEN CAMERA connector optical fiber
cable open circuit error
CCU:PS RCP PWR SUPPLY
NG
Remote control panel
(connected to REMOTE
connector) power supply error
CCU:RX WARNING Transmission error between
camera and CCU
CCU: CAM INVALID FORMAT An invalid format is selected.
