Sony HDCU2000 - Connections and Settings; Fiber Transmission System of Dual Link Format

19
Connections and Settings
Connections and Settings
Fiber Transmission System of Dual Link Format
The camera and the camera control unit are connected via a
single optical fiber cable, and transmission is achieved at
“High Bit Rate.”
Connection example 1
Settings
Camera
MAINTENANCE menu, <SDI OUT> page:
Set SDI-1 OUT to HD PROMPTER.
Camera control unit
Format: Select a Dual Link format of 1080/59.94P or 1080/
50P.
