Specifications
Design and specifications are subject to change without
notice.
Input connectors
AC IN (1), 100 to 240 V AC
RET 1, 2, 3 BNC-type (3)
3G-SDI: SMPTE 424M/425M, 2.970 Gbps/
2.967 Gbps
HD-SDI: SMPTE 292M,
1.485 Gbps/1.4835 Gbps
SD-SDI: SMPTE 259M, 270 Mbps
VBS: 1.0 Vp-p, 75 ohms
REFERENCE BNC-type (2), loop-through output
HD: SMPTE 274M, tri-level sync, 0.6 Vp-p,
75 ohms
SD: Black burst (NTSC: 0.286 Vp-p,
75 ohms/PAL: 0.3 Vp-p, 75 ohms) or NTSC
10F-BB
PROMPTER BNC-type (2), loop-through output, analog
signal, 1.0 Vp-p, 75 ohms
MIC REMOTE D-sub 15-pin (1) (JAE-made DA-C1-J10
recommended)
(switchable to WF REMOTE by an internal
setting)
HD PROMPTER IN BNC-type (1), SMPTE 292M, 75 ohms,
1.485 Gbps/1.4835 Gbps
Output connectors
AUDIO OUT CH1,
CH2
XLR 3-pin, male (2), 0 dBu/–20 dBu/+4 dBu
3G/HD SDI OUTPUT BNC-type (2)
3G-SDI: SMPTE 424M/425M, 0.8 Vp-p,
75 ohms, 2.970 Gbps/2.967Gbps
HD-SDI: SMPTE 292M, 0.8 Vp-p, 75 ohms,
1.485 Gbps/1.4835 Gbps
3G-SDI/HD-SDI selectable
3G/HD SDI OUTPUT
(MONI)
BNC-type (1)
3G-SDI: SMPTE 424M/425M, 0.8 Vp-p,
75 ohms, 2.970 Gbps/2.967 Gbps
HD-SDI: SMPTE 292M, 0.8 Vp-p, 75 ohms,
1.485 Gbps/1.4835 Gbps
3G-SDI/HD-SDI and character ON/OFF
selectable
HD/SD SDI OUTPUT BNC-type (2)
HD-SDI: SMPTE 292M, 0.8 Vp-p, 75 ohms,
1.485 Gbps/1.4835 Gbps
SD-SDI: SMPTE 259M, 0.8 Vp-p, 75 ohms,
270 Mbps
HD-SDI/SD-SDI selectable
HD/SD SDI OUTPUT
(MONI)
BNC-type (2)
HD-SDI: SMPTE 292M, 0.8 Vp-p, 75 ohms,
1.485 Gbps/1.4835 Gbps
SD-SDI: SMPTE 259M, 0.8 Vp-p, 75 ohms,
270 Mbps
HD-SDI/SD-SDI and character ON/OFF
selectable
CHARACTER/SYNC BNC-type (1)
HD SYNC: HD, BTA-S001, tri-level sync,
0.6 Vp-p, 75 ohms
SD SYNC: SD, composite sync, 0.3 Vp-p,
75 ohms
CHARACTER: VBS, 1 Vp-p, 75 ohms,
character ON/OFF selectable
CHARACTER/HD SYNC/SD SYNC
selectable
HD TRUNK OUT BNC-type (1)
SMPTE 292M, 0.8 Vp-p, 75 ohms,
1.485 Gbps/1.4835 Gbps (Available only
when camera single link format is selected.)
Supplied accessories
Number plates (1 set)
Operation guide (1)
Operation manual (CD-ROM) (1)
Optional accessories
AC power cord:
USA and Canada: 1-551-812-XX
Other countries: 1-782-929-XX
Power cord plug holder
USA and Canada: 2-990-242-01
Other countries: 3-613-640-01
HKCU2007 3G/HD SDI Output Expansion Unit
HKCU1001 SD Encoder Unit
HKCU1003 Multi Interface Unit
CCA-5-3 Connection Cable (3 meters/10 feet)
CCA-5-10 Connection Cable (10 meters/33 feet)
RMM-301 Rack Mount Adaptor
Expansion Board
Maintenance manual
Related devices
HDC2000/2500 series Color Video Camera
RCP-1000 series Remote Control Panel
MSU-1000 series Master Setup Unit
CNU-700 Camera Command Network Unit
HZC-CSM10 Camera System Management Software
